Home > Electrical & Electronics > Passive Components > Capacitor > High Voltage Shunt Power Capacitor Power Factor Correction Capacitors
High Voltage Shunt Power Capacitor Power Factor Correction Capacitors
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
JKCN
Model Number:
BFM
Payment & Shipping
Payment Methods:
Port of Shipment:
NINGBO OR SHANGHAI
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
High Quality Induction Heating Capacitor With Water-cooled TubeNegotiableMOQ: 1 Set -
Capacitor for Electric Heating InstallaionNegotiableMOQ: 1 Set
-
High Voltage Shunt Power CapacitorNegotiableMOQ: 1 Set
-
Water Cooling Electric Heat Capacitor (RFM,with CE)US$ 61.6 - 500MOQ: 1 Set
-
Water Cooling Capacitor (RFM,with CE)US$ 61.6 - 500MOQ: 1 Set
Place of Origin
Zhejiang, China
Brand Name
JKCN
Model Number
BFM
Type
Polypropylene Film Capacitor
Application
Hight Voltage
Package Type
Surface Mount
Capacitance
12~500Kvar
Rated Voltage
6.3Kv~12Kv
Operating Temperature
-40~+40 oC
Specifications
1.No violent mechanical virbration2.No harmful gas and vapor
3.No explosive dust
4.Increase power factor
5.High quality
High voltage capacitor is mainly used in the AC Power System with 50/60Hz to improve power factor.The performance conforms to GB3983.2-89(High voltage shunt capacitor) and IEC60871-1
Service Conditions:
1. Altitude: less 1000m;Ambient Temperature:-40oC~+40oC
2. No violent mechanical vibration,no harmful gas and vapor,no electric, and explosive dust in location
3. Continous operation voltage:1.0Un,long-term max.Over-voltage:less 1.1Un
4. Stable over-current(including harmonics current)less 1.43In.
5. Max.Permissible putput: less 1.35Qn
6. Rate Frequency: 50/60HZ
7. Rated Output: 25~500Kvar, 2.005uf to 43.84uf
9. Rated Voltage: 6.3Kv~12Kv
8. The loss angle of dielectric(tg δ)≤0.0003
