MKP Metallized Polypropylene Film AC Power Capacitor

Name: MKP Metallized Polypropylene Film AC Power Capacitor
Brand: JKCN
SKU: 112871627
Availability: InStock

Negotiable MOQ: 1000 Pieces (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Zhejiang, China

Brand Name:

JKCN

Model Number:

CBB65

Zhejiang Jiukang Electric Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

NINGBO OR SHANGHAI

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Zhejiang, China

Brand Name JKCN

Model Number CBB65

Type Other, Polypropylene Film Capacitor, Round

Application Air Conditioner

Package Type Surface Mount

Capacitance 5-100uf

Rated Voltage 250-450vac

Operating Temperature -40~+70

Specifications

Aluminium capacitor is explode-proof structure,applicable to 50/60Hz start and operation in air conditioner,refrigerator etc.

1,small size & light
2,without leaking
3,small tangent in waste angle
4,innocuity

CBB65 is widely applied in single phase ac motor, please check the application and parameter as below:

APPLICATION:

1,A.C single motor,

2,air conditioner

3,pump

4,domestic electric and health-machine.

Technique Data Of Voltage transformer capacitor CBB65:
Shell:	Aluminum case (round or oval)
Rated Capacitance:	250VAC:5-100uF
Rated Capacitance:	450VAC:5-50uF
Rated Voltage:	125VAC~500VAC
Capacitance Tolerance:	+-5% or fulfilled upon request
Ambient Temperature:	40/70/21; 25/85/21
Test Voltage:	T-T: VAC≥2.0Un 5S non-breakdown
Test Voltage:	T-C: VAC≥2000V 10S non-breakdown
Insulation Resistance:	T-T: RjC≥3000MΩ.uF
Insulation Resistance:	T-C: Rj≥1000MΩ
Loss Tangent:	Tanδ≤ 0.003(20 ºC .50/60Hz)
Safety Class:	P1,P2
Executing Standards:	GB/T3667.1-2005, IEC60252-12001
