Help CenterCBB Motor Run Capacitor (CBB65-3A)
Related Products
-
Aluminium Motor Capacitor (CBB65-1B/1C,with CE)US$ 0.459 - 2.95MOQ: 100 Pieces -
Power Capacitor Air Conditioner Spare Part CBB65 CapacitorNegotiableMOQ: 1000 Pieces
-
Motor Capcitor for Air Conditioner(450V 50uf)US$ 0.43 - 2.36MOQ: 1000 Pieces
-
CBB65 sh Capacitor for Motor Running ConditionerNegotiableMOQ: 1000 Pieces
-
CBB65-1C Super Run Capacitor for Motor Running ConditionerNegotiableMOQ: 1000 Pieces
Specifications
Aluminium capacitor is explode-proof structure,applicable to 50/60Hz start and operation in air conditioner,refrigerator etc.Aluminium Capacitor is explode-proof structure,applicable to 50/60Hz start and operation in air conditioner,refrigerator etc. With CE, UL,CQC and RoHS certificates for our capacitor.
Features:
- Capacitance: 5uf ~ 100uf
- Capacitance tolerance: +/-5% to +/-10%
- Working voltage: 250 to 500VAC
- Temperature range: -40 to +70 degrees Celsius
- Lead material: AMP 250 tin-plated brass QCs
- Aluminum can design with safety mechanism device, offering long life and reliable service
- Small size, small loss and self-healing proper
Technical indicators
1.Rated voltage: 200V,250V,400V,450V,500V
2.Rated frequency:50/60Hz
3.Operation mode:Continuous
4.Tangent of loss angle: ≤ 0.2%
5.Capacitor deviation:±5%,±10%
6.Top allowable overvoltage:1.1Un
7.Top allowable overcurrent:1.3In
8.Insulation:Between terminal:2Un.2seconds;None permanent arcover.Between pole and shell:3KV.2seconds;None arc over.
Application
Purpose: Applicable in starting and operating of monophase asynchronous motor with the frequency between 50 to 60 Hz. Of antiflaming characteristics.
Use for motor running in househeld electric appliances as washing machine, aircon-Ditioner Refrigerater 50-60Hz AC powersupply. Safe protection constrution.
We could design and manufacture as customer's specified specs and dimensions. We can products with any
voltage,capacity,outlet line structure and installing requirements.
