Home > Electrical & Electronics > Passive Components > Capacitor > 55+5uf Aluminum Case Motor Run Capacitor Especially for Air Conditioner
55+5uf Aluminum Case Motor Run Capacitor Especially for Air Conditioner
Negotiable
MOQ: 1000 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
JKCN
Model Number:
CBB65
Payment & Shipping
Payment Methods:
Port of Shipment:
NINGBO OR SHANGHAI
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
45uf Aluminum Case Motor Run Capacitor Especially for Air ConditionerNegotiableMOQ: 1000 Pieces -
45+5uf Aluminum Case Motor Run Capacitor Especially for Air ConditionerNegotiableMOQ: 1000 Pieces
-
30+1.5uf Aluminum Case Motor Run Capacitor Especially for Air ConditionerNegotiableMOQ: 1000 Pieces
-
370V 7.5uf Oval Type Aluminum Case Motor Run CapacitorUS$ 0.1 - 2MOQ: 1000 Pieces
-
Anti-explosion Aluminum Case Motor CapacitorNegotiableMOQ: 1000 Pieces
Place of Origin
Zhejiang, China
Brand Name
JKCN
Model Number
CBB65
Type
Other, Polypropylene Film Capacitor, Round
Application
Air Conditioner
Package Type
Surface Mount
Capacitance
5-100uf
Rated Voltage
250-450vac
Operating Temperature
-40~+70
Specifications
Aluminium capacitor is explode-proof structure,applicable to 50/60Hz start and operation in air conditioner,refrigerator etc.Aluminium Capacitor is explode-proof structure,applicable to 50/60Hz start and operation in air conditioner,refrigerator etc. With CE, UL,CQC and RoHS certificates for our capacitor.
Features:
- Capacitance: 12+5uf ~ 50+5uf
- Capacitance tolerance: +/-5% to +/-10%
- Working voltage: 250 to 500VAC
- Temperature range: -40 to +70 degrees Celsius
- Lead material: AMP 250 tin-plated brass QCs
- Aluminum can design with safety mechanism device, offering long life and reliable service
- Small size, small loss and self-healing property
| CBB65 metalized film capacitor | |
| Specification | |
| product name: | CBB65 motor start capacitor |
| product type: | polypropylene film capacitor |
| Model Number: | CBB65 |
| Capacitance: | 1-100uf |
| capacitance tolerance | ± 3%, ± 5%, v± 10% |
| Rated Voltage: | 220V-630VAC |
| Operating Temperature: | -25~70° C |
| Climate type: | 25/70/21 |
| Application: | AC motor, air conditioner, washing machine, water pump and generator. |
| Safety Class: | P1, P2 |
| the Leader type: | Wire/2 pin/4pin |
| Material: | Plastic/metal case |
| Housing Color: | black, white aluminium, grey aluminium, blue |
| product Size: | kinds of different sizes or as customer' s request. |
