USB 32 Way Servo Controller Servo Control Board V4.7 Support PS2 Controller

USB 32 Way Servo Controller Servo Control Board V4.7 Support PS2 Controller thumbnail-1
USB 32 Way Servo Controller Servo Control Board V4.7 Support PS2 Controller thumbnail-2
USB 32 Way Servo Controller Servo Control Board V4.7 Support PS2 Controller thumbnail-3
USB 32 Way Servo Controller Servo Control Board V4.7 Support PS2 Controller thumbnail-4
USB 32 Way Servo Controller Servo Control Board V4.7 Support PS2 Controller thumbnail-5
USB 32 Way Servo Controller Servo Control Board V4.7 Support PS2 Controller thumbnail-6
USB 32 Way Servo Controller Servo Control Board V4.7 Support PS2 Controller photo-1
USB 32 Way Servo Controller Servo Control Board V4.7 Support PS2 Controller photo-2
USB 32 Way Servo Controller Servo Control Board V4.7 Support PS2 Controller photo-3
USB 32 Way Servo Controller Servo Control Board V4.7 Support PS2 Controller photo-4
USB 32 Way Servo Controller Servo Control Board V4.7 Support PS2 Controller photo-5
USB 32 Way Servo Controller Servo Control Board V4.7 Support PS2 Controller photo-6
US$ 23.83 - 28.17 MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
YTF
Model Number:
USB 32 way servo controller
Contact Supplier Request Quote Chat Now
Shenzhen YTF Technology Co., Limited
Payment & Shipping
Payment Methods:
Port of Shipment:
shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name YTF
Model Number USB 32 way servo controller

Product Description

FOR USB 32 way servo controller servo



control board V4.7 support PS2 controller



The new enhancements

A redesigned hardware , all signal isolation. ( Hardware performance 10 times )

2 , all the re- writing code. ( Stability 10 times )

3 , onboard 16M mini U disk, you can store tens of thousands of action groups. ( Up to 50 times )

4 , released an upgrade package every month , into the brush machine age.

5 , full support for PS2 controller and 32 servos control panel.

6, support network function, through the network remote control ( upgrade package will be released in May )

7, support wifi wireless control (purchased wifi module )

8, , linux, IOS, Android full platform support

9 , computer , mobile phone software has simplified Chinese, traditional Chinese , English three languages

The biggest advantage of this product is : You can use computer software to control the robot , or control your servos . Can control 32 servos , high precision (1us), used by the US imported 32 CPU, highly integrated USB interface , stability and accuracy.
Technical Specifications

1. The servo power supply and control panel separately , independent power supply
2. Control Channel : 32 channels simultaneously control . ( Servo speed adjustable )
3. Communication inputs : USB or serial port (TTL)
4. Signal output : PWM ( precision 0.5us).
5. Servo drive Resolution : 0.5us, 0.045 degrees.
6. baud rate range : 9,600,192,003,840,057,600 115,200,128,000 .
7. Support servo : Futaba, Hitec, Fraser , spring, more than 98 percent of the market , such as the steering gear
8. PCB Dimensions : 63.5mm × 43.5mm.
9. mounting hole spacing : 55 * 35.5mm.
10. Storage: Onboard 16M U disk .





USB 32 way servo controller servo control board V4.7 support PS2 controllerUSB 32 way servo controller servo control board V4.7 support PS2 controllerUSB 32 way servo controller servo control board V4.7 support PS2 controllerUSB 32 way servo controller servo control board V4.7 support PS2 controllerUSB 32 way servo controller servo control board V4.7 support PS2 controllerUSB 32 way servo controller servo control board V4.7 support PS2 controllerUSB 32 way servo controller servo control board V4.7 support PS2 controllerUSB 32 way servo controller servo control board V4.7 support PS2 controller
