Help CenterAudio Visual HD Video Camera Usb for Web Conferencing System hd av Supplier
Related Products
-
Definition DVI/SDI Video Conferencing Camera Support Multi-Protocol Communications Conference SystemUS$ 400 - 550MOQ: 1 Set -
OEM 1080p 1920*1280 30fps Wide Angle Skype HD Web Video Camera With Polycom Video Conference SupportUS$ 420 - 500MOQ: 4 Sets
-
HD 20x Optical PTZ Classroom Tracking Camera With HDMI DVI Output Web Video Conference SystemUS$ 600 - 800MOQ: 1 Set
-
20X Video Conference Camera HDMI HD-SDI OutputUS$ 600 - 800MOQ: 1 Set
-
Low Noise&high S/N Ratio Video Conference Camera HD1080/60 20X 255 Preset HDMI( to DVI) HD-SDI OutputUS$ 780 - 900MOQ: 1 Set
Item No. |
KT HD50C |
Image Sensor |
SONY 1/2.5’’Progressive CMOS |
Effective Pixels |
2.38 Megapixels |
Resolution HD |
1080p60/50,1080i60/50,1080p30/25,720p60/50 |
Signal System |
PAL/NTSC |
Lens |
20X optical zoom,f=4.7mm(wide angle end)~94.0 mm(far end) |
Horizontal View Angle |
55.4°(W)~2.9°(T) |
Focus System |
Auto/Manual |
Minimum Illumination |
0.1Lux |
Exposure Control |
Auto/Manual |
Shutter Speed |
1/1~1/10,000s |
Gain |
Auto/Manual |
White Balance |
Auto/ Indoor/Outdoor/Manual |
Image Effect |
Full color/black and white/Electronic flip |
S/N Ratio |
≥50db |
Pan |
355°(max. speed:80°/s) |
Tilt |
-30° to +90° (max. speed: 60°/s) |
Preset Position |
9 preset positions by IR remote controller, 255 preset positions by keyboard controller |
Video Output HD |
DVI, HD-SDI, RJ45(Optional) |
Video Output SD |
CVBS(RCA) |
Control Protocol |
SONY VISCA,PELCO P/D |
Control Mode |
RS-232C,RS-422/485 |
Power |
12V DC(10.8~13.0V DC) |
Power Consumption |
Max. 30W(DC 12V) |
Operating Temperature |
0~40℃ |
Storage Temperature |
-10-60℃ |
Dimensions |
(L)184×(W)166×(H)198mm |
Weight |
1710g |
Color |
Black and Silver |
Accessories |
DC 12V power adapter, IR Remote, Operation manual, RS-232C Cable, DVI adapter, YPbPr/HDMI cable, Ceiling bracket |
Exhibition show:
Q&A
1)What is your minimum order quantity?
-- one full container at least 5sets each model. Sample order is acceptable.
2)Do you have products in stock?
--Some types of video conference camera have, and haven’t.It depend your order module.
3)What is your delivery terms?
--FOB to your country by DHL,Fedex through air.
Payment terms is T/T in advance, Western Union, Paypal ect.
4)When will you ship my order?
--Ordinary,once we get confirmation for payment,we will ship order within 1-3days.
5)The video confence camera doesn’t have the interface I need, what should I do?
--Yes, it might cannot meet your requirement. However, Talk to our sale, the interface we can add to conferencing camera with charging extra fees. We promised : All your need we will try our best to satified you.
6)Can I install the conference camera by myself?
--Of course,the conferencing camera is flexible to install. We supplied camera accompanied with DV 12V power adapter, IR controller, braket, operation menu, RS-232 cable and YPBPR cable.You can install by user manual or you can contact us in need.
7)How about warranty?
--Generally, modules for 1 year, and conference camera for 2 years.
Life-time provide technical consulting.
KATO VISION CO., LIMITED
Phone: +86-755-89500973
Skype: Jenny Kato
TradeManager: cn1511526172
Website: /
Address:4/F, Block B, Dexinchang Industrial Park, Qingxiang Rd., Longhua district, Shenzhen 518109, China
