Help CenterHY13 Motor Rotor Aluminum Casting Hydraulic Press
Related Products
Specifications
Motor Rotor Aluminum Casting Hydraulic Press1, stability, reliability,
2, flexibility, convenient
3,power saving
Name: HY13 Motor Rotor Aluminum Casting Hydraulic Press
Characteristic of HY13 Motor Rotor Aluminum Casting Hydraulic Press :
Aluminum Casting Hydraulic Press (Die-Casting Machine) adopts manual shimming aluminum and fan blade inlet of aluminum process and is controlled by PC programmable controller. It has three word orders of spot moving, manual and semi-automatic, and the work is completed by a triple progress of slowly pressed spraying, fast pressed spraying and pressing. After die-casting, sprue cut on the machine. Y type motor and the similar motor rotor die casting are suitable for this die casting machine. 400kN die-casting machine is mainly used in micro motor rotor die casting such as fan and washing machine, etc with the featuring of small specification, so no need to three level pressing and cut on the machine.
This die-casting machine is with the features of stability, reliability, flexibility, convenient and power saving.
Technical Specification of HY13 Motor Rotor Aluminum Casting Hydraulic Press
| Items | Unit | HY13-40 | HY13-100 | HY13-200 | HY13-500 | HY13-500 | ||
| Range of Motor Rotor die casting | Micro Motor | Y80-Y160 | Y160-Y280 | Y280-Y500 | Y280-Y500 | |||
| Mould Clamping Force | KN | 400 | 1000 | 2000 | 5000 | 5000 | ||
| Injection Force | KN | 100 | 380 | 560 | 2000 | 2000 | ||
| Injection Place | KN | 600 | 900 | 3150 | 3150 | |||
| Blanking Force | KN | 90 | 300 | 1000 | 1000 | |||
| Working Hydraulic Force | Mpa | 25 | 25 | 25 | 25 | 25 | ||
| Slide Stroke | mm | 320 | 600 | 580 | 900 | 900 | ||
| Injection Piston Stroke | mm | 150 | 200 | 250 | 500 | 500 | ||
| The Max. Opening | kg | 520 | 750 | 900 | 1500 | 1500 | ||
| The Max. Note Aluminum Quantity | kg | 6 | 19 | 150 | 150 | |||
| Speed of Slider | Quick Downstream | mm/s | 65 | 100 | 100 | 120 | 120 | |
| Slow Downstream | mm/s | 10 | 16 | 16 | 10 | 10 | ||
| Return | mm/s | 105 | 100 | 80 | 100 | 100 | ||
| Speed of Injection Piston | Slow Injection | mm/s | 155 | 38 | 65 | 45 | 45 | |
| Quick Injection | mm/s | 600 | 1000 | 1000 | 1000 | 1000 | ||
| Return | mm/s | 405 | 100 | 160 | 100 | 100 | ||
| Working Table Size | Length | mm | 400 | 630 | 900 | 1380 | 1380 | |
| Width | mm | 650 | 630 | 900 | 1400 | 1400 | ||
| Electric Motor Power | Kw | 5.5 | 11 | 15 | 74 | 74 | ||
| Overall dimension | Length | mm | 1750 | 2480 | 3100 | 5445 | 5445 | |
| Width | mm | 1150 | 1650 | 4600 | 5518 | 5518 | ||
| Height | mm | 2480 | 3855 | 4450 | 5018 | 5018 | ||
| Weight | kg | 2500 | 7500 | 14000 | 35000 | 35000 | ||
