PFT-100 Aluminum Foil Sealing & Labeling Combined Machine
Structure and characteristics:
A. This machine has the amalgamation of mechanism and electricity. The structure is simple but reasonable, also convenient for maintain. Several protection equipments had been installed.
B. The transmitting belt can regulate by electronic unit stepless. And it is convenient for the selection of sealing speed.
C. Seal a temperature from seal an electric voltage regulate the deal certain, regulate the electric voltage size can get the fit a temperature.
D. There is apparatus to test the aluminum foil automatically and to pickout the waster.
E. Label supply unit is controlled by step motor. There sets speed-adjustable motors drive transmission belt component, labeling component and bottle allocating component separately and make them work coincidence.
F. Hot key printer is controlled by the photoelectric transducer and ensures the label to be pasted smoothly.
G. Quantity of the labels that had been attached can be showed on the controlling table.
Main Technical Specifications:
Type | Production Capacity (Bottle/min) | Specification of bottle(outside diameter/height) (mm) | Labeling specification length/height (mm) | Specification of cap (mm) | Size of the label | Voltage (V) | Overall size(mm) | Weight (kg) |
PFT-100 | 20-120 | Φ20-60/40-120 | 25-180/25-70 | Φ20-50 | Special rolling labeling- sticking belt | 220 | 820×850 ×1200 | 250 |
