Leadshine DM422C-64 pneumatic marking machine stepper motor driver
The DM422C-64 is a versatility fully digital stepping drive based on a DSP with advanced control algorithm. It brings a unique level of system smoothness, providing optimum torque and nulls mid-range instability. The self-test and auto-configuration technology offers optimum responses with different motors and easy-to-use. The driven motors can run with much smaller noise, lower heating, smoother movement than most of the drives on the markets. Its unique features make the DM422C-64 an ideal solution for applications that require low-speed smoothness.
Specifications
| Model | Phase | Current(A) | Voltage(V) | Adaptive motor | Weight(kg) | Dimensions(mm) |
| DM320C | 2 | 0.5-2 | 18-30 DC | 39 42 | 0.1 | 86*55*20 |
| DM422 | 2 | 0.5-2.2 | 18-36 DC | 39 42 | 0.15 | 86*55*20 |
| DM422C | 2 | 0.5-2.2 | 18-36 DC | 39 42 | 0.15 | 86*55*20 |
| DM422C-64 | 2 | 0.5-2.2 | 18-40 DC | 42 57 | 0.23 | 86*55*20 |
| DM432C | 2 | 1.3-3.2 | 18-40 DC | 42 57 | 0.28 | 116*69.2*26.5 |
| DM442 | 2 | 1.4-4.2 | 18-36 DC | 42 57 | 0.2 | 116*69*26.5 |
| DM542 | 2 | 1.0-4.2 | 18-48 DC | 57 86 | 0.23 | 118*75.5*33 |
| DM542-500 | 2 | 1.0-5.0 | 18-48 DC | 57 86 | 0.23 | 118*75.5*33 |
| DM556 | 2 | 2.1-5.6 | 18-48 DC | 57 86 | 0.28 | 118*75.5*33 |
| DM856 | 2 | 2.1-5.6 | 18-70 DC | 57 86 | 0.28 | 118*75.5*33 |
| DM856-SW | 2 | 2.1-5.6 | 18-70 DC | 57 86 | 0.28 | 118*75.5*33 |
| DM870 | 2 | 2.1-7.0 | 18-70 DC | 57 86 | 0.28 | 118*75.5*33 |
| DM860 | 2 | 2.4-7.2 | 18-80 DC | 57 86 | 0.38 | 151*97*48 |
| DMA860H | 2 | 2.0-6.0 | 18-80 DC | 34 42 | 0.57 | |
| DMA860H-DK | 2 | 2.0-6.0 | 18-80 DC | 34 42 | 0.57 | |
| DM1182 | 2 | 2.2-8.2 | 90-130 AC | 86 110 | 1.3 | 200*145*83 |
| DM2282 | 2 | 2.2-8.2 | 180-240 AC | 86 110 130 | 1.7 | 200*145*83 |
Product photos
Applications
Pneumatic marking machine drives
Similar items
| Model | Phase | Current | Voltage | Matching motor | Application |
| DM320C | 2ph | 0.5~2A | 18~30VDC | Nema14 15 17 Motor | Good for Low Speed |
| DM422 | 2ph | 0.5~2.2A | 18~40VDC | Nema14 15 17 Motor | |
| DM422C | 2ph | 0.5~2.2A | 18~40VDC | Nema15 17 Motor | Good for Low Speed |
| DM422C-64 | 2ph | 0.5~2.2A | 18~40VDC | Nema15 17 Motor | Pneumatic Marking Machine |
| DM432C | 2ph | 1.3~3.2A | 18~40VDC | Nema17 23 Motor | Good for Low Speed |
| DM442 | 2ph | 1.46~4.2A | 18~40VDC | Nema17 23 Motor | |
| DM542 | 2ph | 1~4.2A | 20~50VDC | Nema23 34 Motor | |
| DM542-500 | 2ph | 1~5A | 20~50VDC | Nema23 34 Motor | |
| DM556 | 2ph | 2.1~5.6A | 18~50VDC | Nema23 34 Motor | |
| 3DM583 | 3ph | 2.1~8.3A | 24~40VDC | Nema23 34 Motor | |
| DM856 | 2ph | 2.1~5.6A | 18~80VDC | Nema23 34 Motor | |
| DM856-SW | 2ph | 2.1~5.6A | 18~80VDC | Nema23 34 Motor | Sewing Equipment |
| DM860 | 2ph | 2.4~7.2A | 24~60VDC | Nema23 34 Motor | |
| DMA860H | 2ph | 2.4~7.2A | 36~80VDC | Nema34 42 Motor | |
| DMA860H-DK | 2ph | 2~6A | 18~80VAC | Nema34 42 Motor | Carving Machine |
| DM1182 | 2ph | 2.2~8.2A | 60~130VAC | Nema34 42 Motor | |
| DM2282 | 2ph | 2.2~8.2A | 180~240VAC | Nema34 42 52 Motor | |
| 3DM683 | 3ph | 3.2~8.3A | 20~60VDC | Nema23 34 Motor | |
| 3DM2283 | 3ph | 2.2~11.7A | 180~240VAC | Nema34 42 52 Motor |
