Vision Star is a professional manufacturer of surveillance video system devices in China. Our main products including: IP camera, AHD camera, Analog camera, DVR, NVR, HVR and cctv accessories. We are always striving to provide you security cctv cameras with High Quality, Reasonable Price, Fast Delivery, Excellent Service. We sincerely hope to do mutual-beneficial and wonderful business with you.
Analog type Vandalproof Weatherproof
Sony CCD Effio-V 800TVL
WDR, UTC function
best selling cctv DOME camera
Can use wall mounted bracket
IP66 Weatherproof Outdoor Dome CCTV Camera;
1/3" Sony 960H Double -Speed CCD;
DSP: Sony Effio-V CXD4141GG;
Ultra High Resolution 800TVL, 0.0003Low Lux;
Super WDR, 2D&3D-DNR, Sense-up, Defog;
OSD /BLC /Motion Detection /Privacy Masking;
30pcs IR IR-LED, IR Range more than 25M;
2.8-12mm Varifocal lens, manual zooming;
OSD Languages: Chinese,English,Japanese,French,Portuguese,German,Russian,Spanish.
Support UTC function, available for external UTC controller.
Model No. |
VS-V3580IRV |
|
Camera Type |
Color Dome IR Camera |
|
Image Sensor |
1/3" SONY 960H CCD(Dual CCD) |
|
System |
PAL: 663+4141+5148 NTSC: 662+4141+5148 |
|
Effective Pixels |
PAL: 1020(H)x508(V) NTSC: 1020(H)x596(V) |
|
Sync. System |
Internal |
|
Signal System |
PAL /NTSC |
|
Horizontal Resolution |
800TV Lines |
|
Min. Illumination |
0.0003Lux/F1.2 (IR ON 0 Lux) |
|
Lens |
2.8-12MM Varifocal Lens ( 2Mega Pixels ) |
|
IR LED |
30pcs F5 IR LED |
|
Infrared Wavelength |
850 nm |
|
Illuminate Distance |
25M |
|
WDR |
Super WDR |
|
Noise Reduction |
3DNR+2DNR |
|
Sense Up |
Yes |
|
Defog |
Yes |
|
S/N Ratio |
More Than 52dB (AGC Off) |
|
OSD Menu |
LENS: |
AUTO/MANUAL |
SHUTTER/AGC: |
AUTO/MANUAL |
|
FLIP: |
HV/OFF/V/H |
|
LCD/CRT: |
CRT/LCD |
|
SYNC MODE: |
INT |
|
COMMUNICATION |
|
|
SCENE SELECT: |
CUSTOM/FULL AUTO/INDOOR/OUTDOOR/BACKLIGHT/ITS |
|
WDR ATR-EX: |
WDR:CONTRAST/HIGH/MIDDLE/LOW |
|
CLEAR FACE:LOW/MIDDLE/HIGH/OFF | ||
PICT Adjust: |
BRIGHTNESS/CONTRAST/SHARPNESS/HUE/COLOR GAIN |
|
DAY/NIGHT: |
AUTO/DAY/NGHT |
|
HLC/BLC: |
OFF/ HLC/BLC |
|
LANGUAGE: |
Chinese/English/Japanese/German/French /Russian/Portuguese/Spanish |
|
White BAL : |
ATW FRAME/SPEED/DELAY CNT/ENVIRONMENT |
|
S/N : |
OFF/low/middle low/middle/middle high/high |
|
EZOOM: |
ON/OFF |
|
DIS: |
ON/OFF |
|
PRIVACY MASK: |
Area selection/Display/position/color/Transparency/Mosaic |
|
DETEC MOV: |
ACTIVAR/DESACTIVAR |
|
MOTION DET: |
ON/OFF |
|
I/O Connector |
Power: DC Power Jack, Video Output: BNC |
|
Video Output |
1.0Vp-p Composite Output (75Ω / BNC) |
|
Power Supply |
DC12V(+/-10%) |
|
Working Temperature |
-10°C~50°C |
|
Working Humidity |
≤ 95% RH |
|
Dimensions |
140 x 105(H)mm |
|
Weight |
Approx. 0.8kg |
|
We use a color box for camera, then use another carton box to pack it carefully.
Our shipping time is 3-5 working days, by Commercial Express such as DHL, UPS, TNT, Fedex, EMS or Aramex. Or by Post office such as China Post Resigtered Air Mail. The camera price not including any tax rate caused in destination country's Customs.
Each item will be tested and checked before shipping, for any problems after you received, such as damage, defective, please contact us immediately for helping, and please don't hesitate to contact us for any unsatisfying before you open a dispute, we will try our best to offer you a reasonable solution as soon as we can.
