Home > Electrical & Electronics > Variable-Frequency Drive > Leadshine Matching 57mm Nema23 Motor Driver HBS507 3-phase Stepper Motor Driver

Leadshine Matching 57mm Nema23 Motor Driver HBS507 3-phase Stepper Motor Driver

Name: Leadshine Matching 57mm Nema23 Motor Driver HBS507 3-phase Stepper Motor Driver
Brand: Leadshine
SKU: 112777075
Availability: InStock

Leadshine Matching 57mm Nema23 Motor Driver HBS507 3-phase Stepper Motor Driver thumbnail-1

Leadshine Matching 57mm Nema23 Motor Driver HBS507 3-phase Stepper Motor Driver thumbnail-2

Leadshine Matching 57mm Nema23 Motor Driver HBS507 3-phase Stepper Motor Driver photo-1

Leadshine Matching 57mm Nema23 Motor Driver HBS507 3-phase Stepper Motor Driver photo-2

US$ 50 - 100 MOQ: 1 Piece

Key Specifications

Get Latest Price

Place of Origin:

Guangdong, China

Brand Name:

Leadshine

Model Number:

HBS507

Contact Supplier Request Quote Chat Now

Fast To Buy Commerce (Shenzhen) Limited

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen/Hongkong/Guangzhou

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Guangdong, China

Brand Name Leadshine

Model Number HBS507

Motor Type Stepper Motor

Welcome

Thanks for your visiting, for product details, competitive price or more items, welcome to contact Surina directly. :)

Product Description

Leadshine matching 57mm nema23 motor driver HBS507 3-phase stepper motor driver

This Stepper Drive of HBS507 is specilized to maintain you the same model which is made in China from Leadshine company, otherwise,it Will not match you stepper Motor.
Features
Operating voltage range covers 24VDC ~ 70VDC, 24VAC ~ 220VAC;
Support pulse / direction or double-pulse control mode, you can receive differential and single-ended signal instruction, the signal level 5 ~ 24V compatible;
Opto-isolated inputs, anti-interference ability;
Will not lose steps to ensure that the motor precise positioning;
High-speed performance increase of about 30%, improve equipment operating speed;
With variable current control technology, electrical heating decreased by about 20 percent, saving power consumption;
Shorten the response time of the motor acceleration and deceleration;
When the motor stopped without oscillation;
Motor run more smoothly, more accurate;
Without gain adjustment, easier to use.
Electrical indicators

And the number	HBS507
And the number	The minimum value	Typical values	The maximum	unit
The largest peakcurrent	-	-	7	A
The input power supply voltage	18	36	50	Vdc
Logic input current	7	10	16	mA
Pulse frequency	-	200	-	kHz
Insulation resistance	500			M omega.

Dimension

Product photos

Applications

For a variety of small and medium sized automation equipment and instruments, such as: engraving machine, stripping machine, marking machine, cutting machine, laser machines, plotters, medical equipment, machine tools, automatic assembly equipment, electronic processing equipment. In user expectations low noise, high speed device applications particularly good effect.

Related DSP stepper kits

57HS10-EC-1000+HBS86	2ph	1.8°	4.2A	143oz-in	1.0NM	NEMA23	57mm	0-8A	20-50VDC
57HS20-EC-1000+HBS86	2ph	1.8°	5.8A	286oz-in	2.0NM	NEMA23	57mm	0-8A	20-50VDC
60HS30-EC-1000+HBS86	2ph	1.8°	3.0A	429oz-in	3.0NM	NEMA24	60mm	0-8A	20-50VDC
573HBM10-1000+HBS507	3ph	1.2°	5.8A	143oz-in	1NM	NEMA23	57mm	7A	18-48VDC
573HBM20-1000+HBS507	3ph	1.2°	5.8A	286oz-in	2NM	NEMA23	57mm	7A	18-48VDC
1103HBM200H-1000+HBS2206	3ph	1.2°	4.2A	2857oz-in	20NM	NEMA42	110mm	6A	220VAC
1103HBM120H-1000+HBS2206	3ph	1.2°	4.2A	1714oz-in	12NM	NEMA42	110mm	6A	20VAC
