DM542 leadshine 2 phase stepper motor driver original new
Features
Can drive four lines, 8 lines of two-phase stepper motor
Voltage input range: 18 ~ 48 VDC
Current Max: 4.2A, Resolution: 0.1A
Subdivision range: 400 ~ 25600ppr
Signal Input: Differential / Single-Ended, pulse / direction or double pulse, 5 ~ 24VDC level compatible
Impulse Response Frequency: 200KHz
Built-in micro-segmentation
The electrical parameters of the automatic tuning function
Precision current control of the motor heat is greatly reduced
Stationary current is automatically reduced by half
Optically isolated inputs, strong anti-jamming capability
Overvoltage, overcurrent protection function
Specifications
Model |
Phase |
Current(A) |
Voltage(V) |
Microstep resolution |
Adaptive motor |
Weight(kg) |
Dimensions(mm) |
DM422 |
2 |
0.5-2.2 |
18-36 DC |
1-256 |
39 42 |
0.15 |
86*55*20 |
DM442 |
2 |
1.4-4.2 |
18-36 DC |
1-256 |
42 57 |
0.2 |
116*69*26.5 |
DM542 |
2 |
1.0-4.2 |
18-48 DC |
1-256 |
57 86 |
0.23 |
118*75.5*33 |
DM556 |
2 |
2.1-5.6 |
18-48 DC |
1-256 |
57 86 |
0.28 |
118*75.5*33 |
DM856 |
2 |
2.1-5.6 |
18-70 DC |
1-256 |
57 86 |
0.28 |
118*75.5*33 |
DM870 |
2 |
2.1-7.0 |
18-70 DC |
1-256 |
57 86 |
0.28 |
118*75.5*33 |
DM860 |
2 |
2.4-7.2 |
18-80 DC |
1-256 |
57 86 |
0.38 |
151*97*48 |
Product photos
