Shenzhen Vision Star Technology Co.,Ltd., a professional cctv cameras manufacturer, with high quality and competitive price. It located in Shenzhen, Guangdong, China. The main products are CCTV Camera, AHD CCTV Camera, DVR, CCTV Acessories.
1. 1.4Megapixels Color Dome IP camera
2. 1/3” CMOS Sensor SONY IMX238 + HI3518C, high definition 1280 x 960
3. Board Lens 3.6mm or 6mm optional
4. Built-in IR-CUT filter, day night auto switch
5. Advanced H.264 video compression, achieving ultra low bit rate, superb high-definition picture quality.
6. Support various information superimposed(such as DDNS etc.)
7. Support dual-stream
8. Plug and play, with multiple cloud service
9. Support various mobile monitoring (Iphone, Symbian, Android etc.)
10. Support multiple web browser (IE,Chrome,Firefox,Safari), support 2 users log into at the same time
11. Support auto electronic shutter, adapt to different monitoring environment
12. Built-in Web server enables the use of a standard Web browser for viewing and management
13. Standard ONVIF 2.2, support HVR, NVR connection and storage
Specification:
Camera | |
Model No. |
VS-W6114B-IP |
Camera Type |
Color IR Weatherproof IP Camera |
Image Sensor |
1.4MegaPixels 1/3” CMOS Sensor SONY IMX238 |
Main Processor |
HI3518C |
Resolution |
960P |
Effective Pixels |
1280(H) X 960(V) 1.4MP |
Min illumination |
Color 0.01LuxF1.2; B/W 0.001LuxF1.2 (IR ON) |
Lens |
Board Lens 3.6mm or 6mm |
IR Led |
4 Array IR LEDs |
IR Distance |
80M |
Day / Night |
Built-in IR-CUT filter, Day / Night Auto Switch |
S/N Ratio |
≥50db(AGC OFF) |
WDR |
DWER, >100db |
Compression Standard | |
Compression Format |
H.264/MJPEG |
Main Stream |
1280*1024, 1-25(30)FPS; 1280*960, 1-25(30)FPS; 1280*720, 1-25(30)FPS; |
Sub Stream |
720*576, 1-25(30)FPS |
640*480, 1-25(30)FPS | |
Compression Rate |
32 Kbps~16Mbps Continuously adjustable,support CBR/VBRs |
Subtitle Overlay |
Support Channel Name, Date/Time, Stream information Overlay, position is adjustable |
Network &Storage | |
Storage |
Network, HVR, NVR |
Video Recording |
Manual, Auto( Loop, Timer, Alarm, Motion Detection) |
Alarm |
FTP, E-mail, IE, CMS software |
Support Protocol |
TCP/IP, UDP, RTP, RTSP, RTCP, HTTP, DNS, DDNS, DHCP, FTP,NTP,PPPOE,SMTP, UPNP |
Onvif |
Standard Onvif 2.2 |
Remote View |
Support remote view by IE6.0 or above browser (Built-into Web server), support 16 users log into at the same time(MAX) |
Mobile View |
Support Windows Mobile, iPhone, iPad, Android system |
Interface | |
Ethernet |
10M / 100M mbps Ethernet (RJ-45) |
General standard | |
Temperature and Humidity |
-10°C~50°C, humidity less than 95%(no condensation) |
Power Supply |
DC12V±10% / PoE(optional) |
Dimension(mm) |
155mm(L)x68mm(W)x62mm(H) |
Weight |
0.3KG |
We offer 2 years warranty, during this period, for any quality problems please contact us for solving. And we
offer life-time technicial supportings. We tested each camera before shipping, if you found any problems after
received, please contact us immediately. We are trying every effort to keep new progress, we promise to offer
the users high quality products and excellent service. We look forward to establish a long-term business
relationship with you based on integrity and honesty.
