Help CenterSemi-Automatic Tomato Sauce Filling Machine for Small Business
Related Products
-
Semi-Automatic Flammable or Explosive Paste Filling Machine for Small BusinessNegotiableMOQ: 1 Set -
Semi-Automatic Juice Filling MachineNegotiableMOQ: 1 Set
-
Semi-Automatic High Accurancy Olive Oil Filling MachineNegotiableMOQ: 1 Set
-
Semi-Automatic High Accurancy Perfume Filling MachineNegotiableMOQ: 1 Set
-
Automatic Milk Filling Machine for Production LineNegotiableMOQ: 1 Set
Specifications
- Suitable for High Viscous Liquid- Special for various of sauce filling, packaging.
- Full Pneumatic Control
• Suitable for wide range of viscosity fluids and paste. Even with corrosive characteristic.
• Fully pneumatic controlled type is an ideal fill machine for flammable and explosive liquid or viscosity fluid.
• Easy-adjusting design for filling volume adjustment separately or for all pumps. Large range of adjusting dosage.
• Customized plunger ring selection to adapt different filling materials.
• Equipped with International brands of isolation valves, anti-drop device.
• Assurance of key components’ quality by selecting of International reputable brands
• Various control method of filing for semi-auto type.
Issue |
Application Description |
Applicable Filling Materials |
1) Low to High -Viscosity Fluids 2) Applicable for Paste |
Particle Requirement |
Applicable for Liquid or Fluid which consist of small size particle content |
Corrosive Requirement |
Applicable for Liquid or Fluid which consist of Corrosive and Poisonous content |
Typical Filling Material |
Liquids or Paste like: Sauce,Salad dressing , Water , Juice, oil, Medicine, Chemical, Cosmetics and so on |
Best Filling Range |
10ml – 5000ml |
GZGH Catalogue |
GHSLF-P |
||||||
Specific Type |
P6 |
P12 |
P25 |
P50 |
P100 |
P250 |
P500 |
Special Apply for |
Fluids with large of viscosity , even with corrosive, flammable and explosive characteristics |
||||||
Control Method |
Semi-Automatic Note 1 |
||||||
Number of Filling Nozzles |
1 |
1 |
1 |
1 |
1 |
1 |
1 |
Ideal Range of Filling-ml |
25-60 |
50-120 |
100-250 |
200-500 |
400-1000 |
800-2500 |
2000-5000 |
Filling Speed -BPM |
0-50 |
0-50 |
0-50 |
0-50 |
0-50 |
0-40 |
0-30 |
Filling Tolerance |
<= (+/-)1% |
||||||
Compress Air Required |
4-6 bar |
4-6 bar |
4-6 bar |
5-8 bar |
5-8 bar |
5-8 bar |
5-8 bar |
Power Requirement |
Not Applicable |
||||||
Electricity Consumption |
Not Applicable |
||||||
With Hopper |
No Hopper |
||||||
Approximate Weight -G/N |
23/27 |
23/27 |
23/27 |
77/82 |
77/82 |
77/82 |
77/82 |
Dimension ( ‘mm ) |
785*425*530 |
862*412*530 |
918*420*480 |
1112*477*480 |
1175*505*480 |
1342*550*480 |
1264*634*480 |
Note: The semi-automatic control can achieve the 3 modes as below:
a) To start filling by pushing the “start button”.
b) To start filling by stepping on the “start switch” which push on the floor.
c) Can set up the filling in “periodically automatic filling mode”
Following documents are available, but not limited, to be provided upon the stage of purchasing
No |
Document |
Code |
Description |
1 |
Products Selection Guide |
SG |
To select or customize the suitable products for the clients upon the feedback of Selection Guide, which include project background, parameters and other client’s requirement |
2 |
Products Profile |
PP |
To enable the clients understand the overview of the products, Covers sections of Basic Features, Application, Construction, Typical Products, Approvals, and Optional Features |
3 |
Installation Instruction |
IN |
To explain the step of installation of the equipment, and include commissioning instruction as well |
4 |
User Manual |
UM |
To cover the content of Operation & Maintenance and Trouble Shooting |
CE Approval
Customization Philosophy
Our philosophy is to customize your real need, No idle capacity and function. To supply you performance and cost balanced products. Following are the factors shall be taken into account during customization:
a) Filling Materials
b) Container to be filled, type and specification.
c) Capacity requirement
d) Automation requirement
e) Protection requirement
f) Other specific requirement
Selection Guide
Selection Guides are available for circulation, contact us to get products selection support.
