• The Semi-Automatic High Accurancy Olive Oil Filling Machines are not only suitable for olive oil filling ,but also suitable for the other oil filling ,and normal liquids, wide range of viscosity liquids.
• Non-leakage design, the liquids only fill through the flexible tube without touch with the other components
• Less operation cost concept, only consumable is flexible tube.
• Easy-adjusting design for filling volume adjustment.
• Easy-Clean characteristic, change the flexible tube to adapt the filling material changing.
• Equipped with International brands of isolation valves, avoid drop leakage, accurate filling.
• Assurance of key components’ quality by selecting of International reputable brands
• Various control method of filing for semi-auto type.
• Simple maintenance, non-seal sub-assembly design.
Issue |
Application Description |
Applicable Filling Materials |
1) Normal Liquids 2) Low to High -Viscosity Liquids 3) Not applicable for Paste |
Particle Requirement |
Applicable for Liquid or Fluid which consist of small size particle content |
Corrosive Requirement |
Applicable for Liquid or Fluid which consist of Corrosive and Poisonous content |
Typical Filling Material |
Liquids like: Oiler Oil, Massage Oil , Palm Oil and Vegetable Oil, Water , Medicine, Chemical, Cosmetics and so on |
Best Filling Range |
10ml – 100ml |
GZGH Catalogue |
GHSLF-E1 |
GHSLF-E2 |
Control Method |
Semi-Automatic Note 1 |
Semi-Automatic Note 1 |
Number of Filling Nozzles |
1 |
2 |
Range of Filling |
10-100ml |
10-100ml |
Filling Speed |
>=10L/min |
>=10L/min |
Filling Tolerance |
<= (+/-)1% |
|
Compress Air Required |
Not Applicable |
Not Applicable |
Air Consumption |
Not Applicable |
Not Applicable |
Power Requirement |
AC 220V 50/60HZ |
AC 220V 50/60HZ |
Electricity Consumption |
380w |
2*380w |
Explosive-Proof |
Optional Feature |
Optional Feature |
Approximate Weight ( Gross/Net) |
23/18 kg |
29/25 kg |
Dimension ( ‘mm ) |
655*495*386mm |
695*480*385mm |
Note: The semi-automatic control can achieve the 3 modes as below:
a) To start filling by pushing the “start button”.
b) To start filling by stepping on the “start switch” which push on the floor.
c) Can set up the filling in “periodically automatic filling mode”
Following documents are available, but not limited, to be provided upon the stage of purchasing
No |
Document |
Code |
Description |
1 |
Products Selection Guide |
SG |
To select or customize the suitable products for the clients upon the feedback of Selection Guide, which include project background, parameters and other client’s requirement |
2 |
Products Profile |
PP |
To enable the clients understand the overview of the products, Covers sections of Basic Features, Application, Construction, Typical Products, Approvals, and Optional Features |
3 |
Installation Instruction |
IN |
To explain the step of installation of the equipment, and include commissioning instruction as well |
4 |
User Manual |
UM |
To cover the content of Operation & Maintenance and Trouble Shooting |
CE Approval
Customization Philosophy
Our philosophy is to customize your real need, No idle capacity and function. To supply you performance and cost balanced products. Following are the factors shall be taken into account during customization:
a) Filling Materials
b) Container to be filled, type and specification.
c) Capacity requirement
d) Automation requirement
e) Protection requirement
f) Other specific requirement
Selection Guide
Selection Guides are available for circulation, contact us to get products selection support.
