Help CenterHot Sale Forland Flatbed Tow Truck
Related Products
-
HOWO 8X4 Heavy Duty Rotator Tow TruckUS$ 35,000 - 59,000MOQ: 1 Set -
FOTON 4X2 Flatbed Wrecker Tow Trucks For SaleUS$ 10,000 - 35,600MOQ: 1 Set
-
China Heavy Duty Rotator Tow TruckUS$ 30,000 - 65,000MOQ: 1 Set
-
Dongfeng 153 10-13 Ton Heavy-duty Wrecker Towing TruckUS$ 10,000 - 40,000MOQ: 1 Set
-
Dongfeng Tianlong 6x4 Heavy-duty Towing and Lifting WreckerUS$ 10,000 - 40,000MOQ: 1 Set
Specifications
1,Most famous chassis.2,ISO9001-9002.Quality Standard. CCC approved.
3,High quality.
4,fast delivery time.
FORLAND Flat board type tow truck
Summary Hot line( 0086-18727938399 Fax: 0086-0722-3330262 | |||||||
Basic Information | |||||||
Vehicle name |
Tow Truck |
Chassis: |
BJ1083VDJFA |
||||
Outline size(L×W×H) (mm) |
7350*2320*2540 |
Cargo inline size(L×W×H)(mm): |
/ |
||||
Rating mass(kg) |
/ |
Empty mass(Kg): |
5200 |
||||
Full mass(kg) |
8495 |
Emission standard |
Euro 3 |
||||
Engine Information | |||||||
Model |
YZ4DB1-30 |
Type |
6 Cylinder Diesel engine |
||||
Power/displacement(KW/ML) |
95(137HP)/4087 |
Manufacture |
Yangzhou |
||||
Chassis Information | |||||||
Wheelbase(mm): |
3800 |
Axle load(kg) F/R |
3400/5095 |
||||
Tire |
7.50-16,8.25-16,7.50R16,8.25R16 |
Max speed (km/h): |
80/95 |
||||
Front overhang(mm) |
1120 |
Rear overhang(mm) |
1890 |
||||
Front track(mm) |
1688 |
Rear track(mm) |
1630/1600 |
||||
Approach angel(°) |
21 |
Departure angle(°) |
20 |
||||
Steering |
Power steering |
Brake |
Air brake |
||||
Cabin |
3 |
||||||
Special function | |||||||
Flat length x width(mm): 5330*2330 |
Effective length(mm): 1300 |
|
|||||
Flat Stroke(mm): 2680 |
Rated lifting quality(kg):3100 |
|
|||||
Flat minimum inclination angle(°): 8 |
Full extend maximum lift quality(kg):2200 |
|
|||||
Flat maximum bearing quality(kg):3500 |
The rated supporting lead quality(kg):6495 |
|
|||||
Rated traction winch(kg): 4000 |
The length of wire rope(m): 25 |
|
|||||
Trade terms | |||||||
Quote Lifetime |
30days (we promise the quote is effective in the lifetime!) |
||||||
Payment terms |
1. 30% by T/T in advance, 70% by T/T against the copy of Bill-of-Lading. 2. Letter of credit payment for some countries and regions. |
||||||
Deliver time |
30workdays |
||||||
MOQ |
1set |
||||||
Supply quantity |
3,000sets/month |
||||||
Package |
waxing |
||||||
Note:
1.All the data above is for reference ,we keep the right to improve our product.
2..Price will be changed depending on the exchange rate and amount.
