Dongfeng Tianlong 6x4 Heavy-duty Towing and Lifting Wrecker

US$ 10,000 - 40,000 MOQ: 1 Set

Key Specifications

Fuel Type:

Diesel

Emission Standard:

Euro 3

Condition:

New

Hubei Jiangnan Special Automobile Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

any port in China

Delivery Detail:

Delivery time depends on order quantity.

Fuel Type Diesel

Emission Standard Euro 3

Condition New

Transmission Type Manual

Dimensions (L x W x H) (mm) 9100*2480*3600

Place of Origin Hubei, China

Brand Name JDF

Model Number JDF5250TQZDFL

DONGFENG HEAVY-DUTY TOWING TRUCK

Basic Information
Vehicle name	Tow Truck		Chassis:	DFL1250A8
Outline size(L×W×H) (mm)	910024803600		Cargo inline size(L×W×H)(mm):	/
Rating mass(kg)	/		Empty mass(Kg):	19305
Full mass(kg)	25000		Emission standard	Euro 3
Engine Information
Model	ISDe270 30		Type		6 Cylinder Diesel engine
Power/displacement(KW/ML)	198(269HP)/6700		Manufacture		Cummins
Chassis Information
Wheelbase(mm):	4350+1300 ,4350+1350		Axle load(kg) F/R			7000/18000
Tire	10.00-20,10.00R20,11.00-20,11.00R20,295/80R22.5		Max speed (km/h):			80/90
Front overhang(mm)	1460		Rear overhang(mm)			2350/2300
Front track(mm)	1986,2040		Rear track(mm)			1860/1860
Approach angel(°)	20		Departure angle(°)			16
Steering	Power steering		Brake			Air brake
Cabin	2/3
Special function
Maximum lifting of quality(kg): 16000		Effective length (mm):2800
Maximum lifting height(mm):9800		Rated lifting quality(kg):5500
Telescopic crane travel(mm): 3000		Full extend maximum lift quality(kg):3850
Rated traction winch(kg):10000		The rated supporting lead quality(kg):25000
The length of wire rope(m):45
Trade terms
Quote Lifetime	30days (we promise the quote is effective in the lifetime!)
Payment terms	1. 30% by T/T in advance, 70% by T/T against the copy of Bill-of-Lading. 2. Letter of credit payment for some countries and regions.
Deliver time	30workdays
MOQ	1set
Supply quantity	3,000sets/month
Package	waxing
