Specifications
wood door cnc router 13251.stepper or servo motor
2.water or air cooled spindle
3.dsp or nc studio system
wood door cnc router 1325/cnc cutting machine 1325/cnc stone engraving machine 1325/cnc wood engraving machine 1325
Application:
Mainly used for wooden furniture industry like processing wood door, cabinet door, art and craft door, MDF cutting, wood board cutting, engraving wood column and processing other nonmetal materials, etc.
1. The imported straight-line party type guide rail,double row four row ball slide block,loading
capacity,smooth operation,high precision,long life.Import the ball screw high precision,lower knives
accurately.
2. The matching for choose NSK bearings imported from Japan's high-speed water-cooled motor.6 KW
air-cooled spindle 3.0 KW main spindle big power,stable performance.
3. On-line computer typed macro control system,adopting unique intelligent budget rules,give full play
to the motor potential and achieve high speed processing,song linear synchronous,curve more perfect.
4. Software compatibility and can be compatible type3 / Actcam /Castmate /Wentai and so no many
kinds of CAD/CAM design software.
5. Six partition vacuum adsorption mesa,can be effective in different size adsorption material.
6. By using high-speed drive stepping motor and drive,Y axis adopt double motor drive,make high-
speed operation of the 25 m/point above empty line speed,with strong cutting spindle can make the
sculpture speed more improved.
Performance parameters:
X Working Area |
1300mm |
Y Working Area |
2500mm |
Z Working Area |
200mm |
Table size |
1300x2500mm |
Traveling Positioning Accuracy |
±0.05mm |
Repositioning Positioning Accuracy |
±0.05mm |
Table Surface |
By suction |
X,Y ,Z Structure |
XY gear wheel, Z ball screw |
Max. Power Consumption(Without spindle) |
1840W |
Max. Rapid Travel Rate |
50000mm/min |
Max. Working Speed |
25000mm/min |
Spindle Power Motor |
3.0KW |
Spindle Speed |
0-24000r/min |
Drive System |
Stepper |
Working voltage |
AC380V/60Hz |
Command |
G-code |
The machines in our factory
adverisement cnc router machine
4 axis rotary multi heads cnc router
heavy cnc router
wood door cnc router 1325 Samples
>Before-sale service
1)Offer technical consult.
Within 24 hours,according to your demands,we will provide you with any special
technology,product price,and mail sample and product information to you,or give you a
quick reply about the questions you care.We also can make the engrave or cutting video
according to you demand.
2)Offer visitation and reception
We welcome you to visit our factory at any time,and offer you convenience without charge
>on- purchase sale service
Regardless of old customers or new customer,big product value or small product value,we
treat you with faith,equal,enthusiasm,accuracy.
3)After-sale service
Since we are the direct manufacturer,have special technicians to do after-sale
service.Since the day when u have received the machine,you can ask the after-sale
service.No matter what questions or problems,we will do our best to help you.
If you still don’t know how to use the machine after read the manual,it also dosen’t
matter,we can teach you step by step via video or remote control.
About the machine warranty,one year for the whole machine direct from the factory,6 months for the laser tube.
