Chinese Advance Marine Gearbox planetary gearbox HCD138 for Marine Engine used
- 200 Unit / Units per Month
- Shanghai or any other ports in China
- T/T
Product Details
Place of Origin: | Zhejiang, China | Brand Name: | Advance | Model Number: | HCD138 |
Gearing Arrangement: | Planetary | Output Torque: | 40KN | Input Speed: | 1000-2500r/min |
Product Description
Chinese Advance Marine Gearbox planetary gearbox HCD138 for Marine Engine used
Description:
Marine Gearbox HCD138 possesses functions of speed reduction, ahead and astern clutching and bearing propeller thrust. It is designed of vertically offset and one-stage transmission, featuring in large in ratio, small in volume and light in weight.
Main Data:
Input speed | 1000-2500r/min | ||
Reduction ratio | 5.05,5.63 | Trans. capacity | 0.110kw/r/min |
6.06 | 0.099kw/r/min | ||
6.47 | 0.093kw/r/min | ||
Control way | Push-and-pull flexible shaft, electrically, pneumatically | ||
Rated thrust | 40KN | ||
Center distance | 296mm | ||
L×W×H | 494×800×870mm | ||
Net weight | 415kg | ||
Flywheel | 6135Ca,SAE14,11.5 | ||
Bell housing | 6135Ca,SAE1,2 |
Application:
Marine Gearbox HCD138 is suitable for medium and small fishing, transport, tug, transport and passenger boats.
