100KW-200KW Weichai Main Marine Diesel Engine Generator Set with CCS

Name: 100KW-200KW Weichai Main Marine Diesel Engine Generator Set with CCS
Brand: Weichai
Availability: InStock

FOB Price

USD $10,000 - $80,000 / Set

1 Set(Min.Order)

Supply Ability 100 Set / Sets per Month
Port ANY PORT IN CHINA
Payment TermsT/T

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Fujian, China	Brand Name	Weichai
Model Number	CCFJ	Output Type	AC Three Phase
Speed	1500/1800RPM	Frequency	50/60HZ
Rated Power	100-200KW	Rated Voltage	440/230V
Rated Current	180-360A

Product Description

Specifications

100KW-200KW Weichai Main Marine Diesel Engine Generator Set with CCS
1. Famous engine
2. High performance
3. Good prices

100KW-200KW Weichai Main Marine Diesel Engine Generator Set with CCS

WD615/618 Series Marine Generating Setsare powered by WD615/618 series diesel engines and fitted up with renowned generators. The rotating speed is 1500 rpm or 1800rpm, and the power output range is 64-200kW. These generating sets are widely used as common marine generating set and marine emergency generating sets, Css and /or ZY, BV certification can be supplied.

GB/T13032-1991 Standard is applied for the manufacture and inspection of the generating sets.

Main components of the generating sets:

Alternator: Marathon, Stanford and Lanzhou generator with F or H insulation grade.

Parallel function: Two and more normal marine generating sets can transfer loading without stoping, and can realize parallel.

Portection function: There are over-limit alarming for speed, oil pressure and cool-water temperature.

Model List of WD615/WD618 Series Marine Generating Set

Genet Model	Continuous output(kW)	Rated Voltagey(V)	Rated currency(A)	Rated loading fuel consump(kg/h)	Weichai WD615/WD618 Series Diesel Engine						Exciting method	Alternator Manufacturer
Genet Model	Continuous output(kW)	Rated Voltagey(V)	Rated currency(A)	Rated loading fuel consump(kg/h)	Engine model	Max output(kW)	Rated speed(r/min)	Governing method	Starting method	Cooling method	Exciting method	Alternator Manufacturer
CCFJ100J-WI	100	400	181	20	WD615.61CD	129	1500	Electrical	Electrical	Dual-circulation water-cool	Brushless	Marathon
CCFJ120J-WI	120	400	217	24	WD615.67CD	152	1500	Electrical	Electrical	Dual-circulation water-cool	Brushless	Marathon
CCFJ150J-WI	150	400	271	30	WD615.68CD	187	1500	Electrical	Electrical	Dual-circulation water-cool	Brushless	Marathon
CCFJ180J-WI	180	400	325	36	WD615.46CD	231	1500	Electrical	Electrical	Dual-circulation water-cool	Brushless	Marathon
CCFJ200J-WI	200	400	361	40	WD61842CD	259	1500	Electrical	Electrical	Dual-circulation water-cool	Brushless	Marathon
CCFJ100J-WU	100	400	181	20	WD615.61CD	129	1500	Electrical	Electrical	Dual-circulation water-cool	Brushless	Stamford
CCFJ120J-WU	120	400	217	24	WD615.67CD	152	1500	Electrical	Electrical	Dual-circulation water-cool	Brushless	Stamford
CCFJ150J-WU	150	400	271	30	WD615.68CD	187	1500	Electrical	Electrical	Dual-circulation water-cool	Brushless	Stamford
CCFJ180J-WU	180	400	325	36	WD615.46CD	231	1500	Electrical	Electrical	Dual-circulation water-cool	Brushless	Stamford
CCFJ200J-WU	200	400	361	40	WD618.42CD	259	1500	Electrical	Electrical	Dual-circulation water-cool	Brushless	Stamford
CCFJ100J-WE	100	400	180	20	WD615.61CD	129	1500	Electrical	Electrical	Dual-circulation water-cool	Brushless	Lanzhou
CCFJ120J-WE	120	400	217	24	WD615.67CD	152	1500	Electrical	Electrical	Dual-circulation water-cool	Brushless	Lanzhou
CCFJ150J-WE	150	400	271	30	WD615.68CD	188	1500	Electrical	Electrical	Dual-circulation water-cool	Brushless	Lanzhou
CCFJ180J-WE	180	400	325	36	WD615.46CD	231	1500	Electrical	Electrical	Dual-circulation water-cool	Brushless	Lanzhou
CCFJ200J-WE	200	400	361	40	WD618.42CD	259	1500	Electrical	Electrical	Dual-circulation water-cool	Brushless	Lanzhou

Technical Parameters for Weichai WD615/618 Series Marine Generating Sets

Model	Weichai WD615 series
Type	In line, four-stroke, water-cooled, dry cylinder liner, direct injection
Cylinder numbers	6
Intake method	Turbocharged, or turbocharged intercooled
Bore/stroke(mm)	126/130
Displacement(L)	9.726
Min fuel consumption(g/kW.h)	≤197
Min oil consumption(g/kW.h)	≤0.5
Idle speed(r/min)	600±50
Noise dB(A)	≤108
Stable governing rate	≤5%
Firing sequence(from free end)	1-5-3-6-2-4
Starting method	Electric starting
Cooling method	Forced dual-circulation water cooling
Smoke Bb	≤1.0
Lubricating method	Forced Lubricating

Model	Weichai WD618 series
Type	In line, four-stroke, water-cooled, dry cylinder liner, direct injection
Cylinder numbers	6
Intake method	Turbocharged, or turbocharged intercooled
Bore/stroke(mm)	126/155
Displacement(L)	11.596
Min fuel consumption(g/kW.h)	≤197
Min oil consumption(g/kW.h)	≤0.5
Idle speed(r/min)	600±50
Noise dB(A)	≤108
Stable governing rate	≤5%
Firing sequence(from free end)	1-5-3-6-2-4
Starting method	Electric starting
Cooling method	Forced dual-circulation water cooling
Smoke Bb	≤1.0
Lubricating method	Forced Lubricating
