Help CenterChina Weichai 6170 Marine Generator Set for Sale 200-250kw
Related Products
-
Factory Prices ! 200KW Marine Diesel Power Generator Set With ATS / Deepsea in Stock for SalingUS$ 1 - 200,000MOQ: 1 Set -
China Weichai Marine Generator Set for Sale 200-250kwUS$ 1 - 100,000MOQ: 1 Piece
-
Marine Diesel Generator Set 30kw to 1000kw CCS ApprovedUS$ 10,000 - 80,000MOQ: 1 Set
-
Marine Diesel Genset CCS & BV Approved for Ship Material With Cheapest Price and Fast ShipmentUS$ 1,500 - 20,000MOQ: 1 Set
-
Yuchai Marine Diesel Generator Set CCS & BV Approved for Ship Emergency UseUS$ 1,500 - 20,000MOQ: 1 Set
Equipped with well known motors like Landian, Simens, and Marathon, 170Z series marine diesel power generator unit is powered by 170Z diesel engines produced by Weichai. In addition, its rotation speed can reach 1,000r/min, 1,200r/min or 1,500r/min respectively. Its power range is between 250kW-400kW. CCS and ZY can be provided upon request. The components of the power generator unit: Motors: Marathon, LEC, Siemens and other well-known brand in China; the insulation class is F Grade and above. Parallel connection: marine diesel power generator unit can realize load transfer for two units without power off, thus capable of parallel operation. Protection: the generator unit will activate its alarming system when its rotation speed, oil pressure, cooling water temperature or oil temperature exceeds the limit. Main Features: The power generator unit delivers excellent performance; With compact structure and excellent performace, 170Z series power generator unit boasts can be easily operated and maintained. Moreover, it is highly powerful and reliable. The power generator is highly safe and reliable The power generator unit adopts brand name motors, including Landian, SiemensMarathon, etc.
Model |
A |
A1 |
B |
L |
L1 |
W1 |
W |
H |
R |
D |
CCFJ250J-WD |
560 |
408 |
960 |
3596 |
3408 |
1050 |
1146 |
1909 |
12 |
27 |
CCFJ300J-WD |
560 |
408 |
960 |
3596 |
3408 |
1050 |
1146 |
1909 |
12 |
27 |
CCFJ400J-WD |
596 |
560 |
1000 |
4828 |
4538 |
1050 |
1186 |
2004 |
16 |
27 |
CCFJ350J-WD |
560 |
408 |
960 |
3596 |
3408 |
1050 |
1146 |
1909 |
12 |
27 |
CCFJ400J-WD1 |
560 |
408 |
960 |
3596 |
3408 |
1050 |
1146 |
1909 |
12 |
27 |
CCFJ500J-WD |
596 |
560 |
990 |
4828 |
4538 |
1050 |
1186 |
2004 |
16 |
27 |
CCFJ600J-WD |
596 |
560 |
990 |
4828 |
4538 |
1050 |
1186 |
2004 |
16 |
27 |
Installation and overall dimension of 170 series generator set (Marathon generator)
Model |
A |
A1 |
B |
L |
L1 |
W1 |
W |
H |
R |
D |
CCFJ250J-WH |
560 |
408 |
960 |
3546 |
3358 |
1050 |
1146 |
1909 |
10 |
27 |
CCFJ300J-WH |
560 |
408 |
960 |
3546 |
3358 |
1050 |
1146 |
1909 |
12 |
27 |
CCFJ400J-WH |
560 |
560 |
960 |
4778 |
4488 |
1050 |
1146 |
1954 |
14 |
27 |
*CCFJ350J-WH |
560 |
408 |
960 |
3546 |
3358 |
1050 |
1146 |
1909 |
12 |
27 |
*CCFJ400J-WH1 |
560 |
408 |
960 |
3546 |
3358 |
1050 |
1146 |
1909 |
12 |
27 |
CCFJ500J-WH |
560 |
560 |
1200 |
4478 |
4488 |
1050 |
1146 |
1954 |
16 |
27 |
CCFJ600J-WH |
560 |
560 |
1200 |
4478 |
4488 |
1050 |
1146 |
1954 |
16 |
27 |
Installation and overall dimension of 170 series generator set (Siemens generator)
Model |
A |
A1 |
B |
L |
L1 |
W1 |
W |
H |
R |
D |
CCFJ300J-WX |
560 |
700 |
1200 |
3784 |
3597 |
1284 |
1380 |
1909 |
12 |
27 |
CCFJ400J-WX |
560 |
560 |
1200 |
4468 |
4212 |
1290 |
1386 |
2004 |
16 |
27 |
*CCFJ350J-WX |
560 |
408 |
1050 |
3540 |
3320 |
1146 |
1242 |
1909 |
12 |
27 |
*CCFJ400J-WX1 |
560 |
408 |
960 |
3467 |
3235 |
1050 |
1146 |
1909 |
12 |
27 |
CCFJ500J-WX |
560 |
560 |
1200 |
4468 |
4212 |
1300 |
1406 |
2004 |
16 |
27 |
CCFJ600J-WX |
560 |
560 |
1200 |
4468 |
4212 |
1300 |
1406 |
2004 |
16 |
27 |
Installation and overall dimension of 170 series generator set (LEC generator)
Model |
A |
A1 |
B |
L |
L1 |
W |
H |
R |
D |
CCFJ200J-WD |
880 |
160 |
1010 |
3441 |
3018 |
1100 |
1950 |
8 |
30 |
CCFJ250J-WD |
880 |
160 |
1010 |
3669 |
3114 |
1100 |
1950 |
8 |
30 |
Installation and overall dimension of 170 series generator set (Marathon generator)
Model |
A |
A1 |
B |
L |
L1 |
W |
H |
R |
D |
CCFJ200J-WH |
880 |
160 |
1010 |
3391 |
2968 |
1100 |
1950 |
8 |
30 |
CCFJ250J-WH |
880 |
160 |
1010 |
3619 |
3064 |
1100 |
1950 |
8 |
30 |
Note: dismension of the above generator set is calibrated in accordance to 1000rpm, 400V and IP23.
The frequency of generator set listed in this table is 50Hz (60Hz generator sets could be provided on request). Power factor is 0.8 (lag). Mode of wiring is three-phase four-wire system.
Technical specification of 170 series diesel engine:
Model |
6/8-cylinder, water-cooling, in-line, four-stoke, direct injection |
Bore/Stroke (mm) |
170/200 |
Displacement (L) |
27.24/36.32 |
Compression ratio |
14.5:1 |
Fuel oil consumption (g/kW.h) |
≤197 |
Idling (r/min) |
450±50 |
Steady speed adjusting ratio (%) |
≤5 |
Start mode |
Electrical start / pneumatic start |
Noise dB(A) |
≤112 |
Displacement of oil pan (L) |
120 |
Rotation direction of crankshaft |
Counterclockwise (facing the flywheel end) |
Technical specification of 170 series marine diesel generator set
Speed (r/min) |
1000,1500/1200 |
Power (kW) |
250/300/350/400 |
Pressure (V) |
400/440 |
Frequency (Hz) |
50 /60 |
Start mode |
Electrical start/pneumatic start |
Power factor |
0.8 (lag) |
Cooling mode |
Dual-circulation water-cooling |
Speed regulation mode |
Mechanical/mechanical plus accelerator servo mechanism/electrical |
