TBD 620 Series of Diesel Engine Developed From Deutz Diesel Engine

TBD 620 Series of Diesel Engine Developed From Deutz Diesel Engine thumbnail-1
TBD 620 Series of Diesel Engine Developed From Deutz Diesel Engine photo-1
US$ 20,000 - 90,000 MOQ: 1 Piece
Key Specifications
Get Latest Price
Condition:
New
Engine:
4 Stroke
Engine Capacity:
> 6L
Contact Supplier Request Quote Chat Now
Xiamen Sitaiqi Industry & Trade Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai or other ports in China(Mainland)
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Engine 4 Stroke
Fuel Type Diesel
Cylinders 6
Engine Position Inboard
Dimensions (L x W x H) (mm) 2395*1378*2038(mm)
Product Description

 TBD620 Series Diesel Engine developed from technology of DEUTZ-MWM, is one of the most advanced level of diesel engine in the world. Up to now, they have got the International Association Classification Society Certificates of CCS,ZY,ABS, GL,BV,DNV and LR, Having been exported to more than 50 countries and regions in Asia, Europe, Africa, America and Oceania.

Main features of TBD620 Diesel Engines: Good economy, Good startability and speeding-up performance, High reliability, Long service life, Good performance at low load, Easy maintenance and Less cost of maintenance, Compact structure, Small size, Light weight; they can meet the emission requirement of IMO Nox.



TBD 620 Series of Diesel Engine developed from Deutz Diesel Engine

Product Application

 TBD620 series are not only widely used in ship field such as Military equipment, Commercial cargo ship, Passenger ship, Tourist ship, Working ship, Fishing ship and High-speed vessel but also in other fields such as Petroleum industry, Coal industry, Construction,Mining, Nuclear power station, Hydropower station, Emergency/fire pump and Special vehicles.



Main Technical Data



Model TBD620-V8 TBD620-V12 TBD620-V16
Bore/Stroke 170mm/195mm
Cylinder Arrangement Line/V-90°
Number of Cylinder 8 12 16
Unit Cylinder Volume 4.43dm³
Total Cylinder Volume 35.4dm³ 53.16dm³ 70.88dm³
Dimension 2340*1450*2153 (mm) 2979*1450*2240 (mm) 3400*1450*2180 (mm)
Dry Weight 3600 kg 5100 kg  6290 kg
Compression Ratio 13.5:1
Rated Power 830kw-1700kw
Max.Combustion Pressure 17Mpa
Min.Steady Speed 650r/min
Ignition Speed 150r/min
Direction Anti-clockwise rotation (from flywheel end)
Lub. Oil Combustion ≤1g/kw·h
Emissions IMO Tier II
