Umbrella Plastic Parts Making Molding Machine
US$ 1 - 50,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Product Type:
Other, PLASTIC MACHINE
Place of Origin:
Zhejiang, China
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
70T Toothpick Bottle Making Plastic Injection MachineUS$ 1 - 50,000MOQ: 1 Set -
Fixed Pump Injection Moulding MachinesUS$ 1 - 50,000MOQ: 1 Set
-
Good Price of Small Injection Moulding MachinesUS$ 1 - 50,000MOQ: 1 Set
-
Energy Saving Injection Moulding MachineUS$ 1 - 50,000MOQ: 1 Set
-
Shuangsheng 70T Plastic Automatic Injection Moulding Machine With Fixed PumpUS$ 1 - 50,000MOQ: 1 Set
Condition
New
Product Type
Other, PLASTIC MACHINE
Place of Origin
Zhejiang, China
Brand Name
SS
Model Number
SSF700-K5
Voltage
380V
Power(W)
50HZ
Dimension(L*W*H)
3.6m*1.2m*1.65m
Weight
2.2
Certification
CE
Warranty
One year
After-sales Service Provided
Overseas third-party support available
Umbrella plastic parts making molding machine
We are leading small injection moulding machine manufacturer in Ningbo,China, the largest plastic industry city, with over 12 years manufacturing experience. Our machines are included but not limited small color match chips injection molding machines special designed for masterbatch and pigment suppliers, plastic small gears making injection machines, variable pump injection machines, servo motor injection moulding machines, of which are widely used at home appliance equipments, automobile industry, daily life industry, masterbatch and pigment industry, medical industry and ect.
Main technical datas of 70T plastic injection molding machine as below;
| Items | Parameter | Unit | Parameter Value (SSF700) | |
| Injection Unit | Screw diameter | mm | A | B |
| 34 | 36 | |||
| Screw L/D ratio | L/D | 18.8 | 17.7 | |
| shot volumn (theoretical) | Cm3 | 113 | 127 | |
| injection weight(PS) | g | 103 | 115 | |
| plasticizing capacity | g/s | 11.6 | 13 | |
| injection rate | g/s | 86 | 96 | |
| injection pressure | Mpa | 171 | 153 | |
| screw speed | rmp | 180 | ||
| Clamping unit | clamp force | KN | 700 | |
| open stroke | mm | 270 | ||
| space between bars (W*H) | mm | 315*300 | ||
| max mould height | mm | 320 | ||
| min mould height | mm | 150 | ||
| ejector stroke | mm | 80 | ||
| ejector force | KN | 27 | ||
| ejector number | PC | 1 | ||
| mould align diameter | mm | 100 | ||
| Others | max pump pressure | Mpa | 16 | |
| pump motor power | KW | 7.5 | ||
| heating power | KW | 5.1 | ||
| machine dimension | m | 3.6*1.2*1.65 | ||
| machine weight | T | 2.2 | ||
| oil tank capacity | L | 130 | ||
The machine is applied to produce the umbrella plastic spare parts such as button, head and etc with multi-cavities.
One mold 12cavities, raw material PE;
One mold 20 cavities, raw material PC;
If you have any query about our injection molding machine, just contact me at any time Alexis Liao Mobile photo:+8613806673276(whats app&we chat ID)
QQ:1159033100
