Small Injection Moulding Machine for Exportation
US$ 1 - 50,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Product Type:
Other, PLASTIC MOULDING MACHINE
Place of Origin:
Zhejiang, China
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
50T Energy Saving Injection Molding Machine ExporterUS$ 1 - 50,000MOQ: 1 Set -
Plastic Parts Making Injection Molding MachineUS$ 1 - 50,000MOQ: 1 Set
-
Best Selling 50Ton Injection Moulding MachineUS$ 1 - 50,000MOQ: 1 Set
-
50T Plastic Injection Molding MachineUS$ 1 - 50,000MOQ: 1 Set
-
Hot Sale Fixed Pump Plastic Injection MachineUS$ 1 - 50,000MOQ: 1 Set
Condition
New
Product Type
Other, PLASTIC MOULDING MACHINE
Place of Origin
Zhejiang, China
Brand Name
SS
Model Number
SSF500-K5
Voltage
380V
Power(W)
50HZ
Dimension(L*W*H)
3.2M*1.1M*1.6M
Weight
1.9T
Certification
CE
Warranty
one year
After-sales Service Provided
Overseas third-party support available
Small plastic 50T injection molding machine with customized color.
It to be ready for exporting to South Africa, with power 380V,50HZ,3Phases.
The machine Standard Features
1.Colorful Techmation controller with optional languages;
2.Chrome plated tie bars with double-cylinder balanced injection system;
3.Auto lubrication system;
4.Mould data memory system, can save 199 set molds data;
5.Multi-stage pressure &speed injection;
6.Back pressure adjustment device;
7.Low pressure mold protection;
8.Mechanical, electrical safety device;
9.Automatic mould adjustment function;
10.Automatic purge function.
Available Options
1.By pass oil filter;
2.Oil temperature controller;
3.USB port data connecting;
4.Hopper dryer;
5.Mold clamps;
6.Vickers directional valves;
7.1PC core valve for SSF380,SSF500,SSF700,
8.2PCS core valves for SSF900,SSF1180,SSF1480,SSF1680;
9.2PCS air valve for machine SSF380 and above;
10.3 Color alarm light;
11.Ceramic heater bands;
12.Water flow regulator;
13.Special screw designs for PA66,PVC,PC production;
14.Customized color (color sample for comparison required);
15.Hydraulic safety mechanism.
16.Merli or Keba PLC
17.Novo transducers
18.Nozzle protection cover
16.Merli or Keba PLC
17.Novo transducers
18.Nozzle protection cover
19.SSR to reduce noise
Spare parts
1.Manual for machine and controller;
2.1 Set various O-rings;
3.1PC extended nozzle;
4.1Barrel lubrication oil;
5.Professional tools such as wrench, screw drivers;
6.1Set crash pad(6pcs)
Main machine techincal parameters;
Main machine techincal parameters;
| Injection Unit | Screw diameter | mm | 28 |
| Screw L/D ratio | L/D | 19 | |
| shot volume(theoretical) | Cm3 | 70 | |
| injection weight(PS) | g | 64 | |
| injection rate | g/s | 43 | |
| injection pressure | Mpa | 224 | |
| screw speed | rmp | 200 | |
| Clamping unit | clamp force | KN | 500 |
| open stroke | mm | 250 | |
| distance between tie bars (W*H) | mm | 290*270 | |
| max mould thickness | mm | 300 | |
| min mould thickness | mm | 100 | |
| ejector stroke | mm | 65 | |
| ejector force | KN | 20 | |
| ejector number | PC | 1 | |
| dia of mould location hole | mm | 100 | |
| Others | max pump pressure | Mpa | 16 |
| pump motor power | KW | 5.5 | |
| heating power | KW | 4.7 | |
| machine dimension | m | 3.2*1.1*1.6 | |
| machine weight | T | 1.9 | |
| oil tank capacity | L | 115 |
Oil filter;
Air blast and core pulling valve;
We make injection molding machines strictly follow ISO9001:2008 quality requirements, per customers's special requirements, CE also can be optional.
We shuangsheng plastic machinery respects staffs and values partnership of each customer, each cooperators, that why we can grow smoothly and steadily even the international ecomonic situation is not so optimistic.
The orgnization chart of our company, average working life of the staffs is 8 years.
Organization chart
If you have any query about our injection molding machine, just contact me at any time Alexis Liao Mobile photo:+8613806673276(whats app&we chat ID)
QQ:1159033100
