Injection Moulding Machine Manufacturers

Injection Moulding Machine Manufacturers thumbnail-1
Injection Moulding Machine Manufacturers photo-1
US$ 1 - 50,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Preform Injection
Style:
Horizontal
Contact Supplier Request Quote Chat Now
Ningbo Shuangsheng Plastic Machinery Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Preform Injection
Style Horizontal
Brand Name Shuangsheng
Model Number all kinds
Place of Origin Zhejiang, China
Plastic Type Thermoplastic
Automatic Yes
Injection Weight 27~400G
Injection Rate 35~196G/S
Clamping Force 320~1680KN
Opening Stroke 155~435MM
Power(W) 5~30
Certification ISO9001:2008,CE
After-sales Service Provided Engineers available to service machinery overseas

Small-sized plastic injection molding machine parameters, there will have one model machine ok for you.

Items Parameter Unit Parameter Value (SSF320) Parameter Value  (SSF380) Parameter Value  (SSF500) Parameter Value (SSF700) Parameter Value (SSF900) Parameter Value (SSF1180) Parameter Value (SSF1480) Parameter Value (SSF1680)
Injection Unit Screw diameter  mm A B A B A B A B A B C A B C A B C A B C
22 25 27 30 28 30 34 36 32 35 38 35 38 42 38 42 45 42 45 50
Screw L/D ratio L/D 17.7 15.5 18.4 16.5 19 17.7 18.8 17.7 24.8 22 20 22 20.2 18.4 22.1 20 18.6 23.6 22 19.8
shot volume(theoretical) Cm3 30 38 48 58 70 80 113 127 112 134 158 163 192 235 226 277 318 311 357 441
injection weight(PS) g 27 34 44 53 64 73 103 115 102 122 144 148 175 213 206 252 289 283 325 402
injection rate g/s 25 32 35 43 43 49 86 96 90 107 126 89 105 128 94 115 132 138 160 196
injection pressure Mpa 185 143 187 151 224 195 171 153 208 174 148 219 186 152 208 171 149 203 177 143
screw speed rmp 165 170 200 180 220 210 185 180
Clamping unit clamp force KN 320 380 500 700 900 1180 1480 1680
open stroke mm 155 235 250 270 290 350 380 435
distance between tie bars (W*H) mm 245*195 240*240 290*270 315*300 360*320 370*370 410*410 460*460
max mould thickness mm 260 270 300 320 380 380 450 520
min mould thickness mm 80 80 100 150 150 150 160 180
ejector stroke mm 40 60 65 80 80 120 120 135
ejector force KN 13 17.5 20 27 31 38 50 50
ejector number PC 1 1 1 1 5 5 5 5
dia of mould location hole mm 55 80 100 100 125 125 125 125
Others max pump pressure Mpa 14 14 16 16 16 16 16 16
pump motor power KW 3 4 5.5 7.5 9 13 13 18.5
heating power KW 2.6 3.2 4.7 5.1 6 7.3 9.3 12.3
machine dimension m 2.80*0.86*1.35 2.9*1.0*1.4 3.2*1.1*1.6 3.6*1.2*1.65 4*1.27*1.75 4.3*1.28*1.9 4.5*1.35*1.9 5.13*1.45*2.12
machine weight T 1.05 1.35 1.9 2.2 2.9 3.4 4 6
oil tank capacity L 85 90 115 130 150 230 250 300



 We Shuangsheng specialized in precise small injection molding machines, with tailored made machines, welcome your inquiry and get more understanding of us.





If you have any query about our injection molding machine, just contact me at any time

Mobile photo:+8613806673276(whats app&we chat ID)

QQ:1159033100
