Test injection moulding machine for masterbatch manufacturer
Shuangsheng Brand professional color chips making injection molding machines is special designed for manufacturers deal with masterbatches and pigments, of which are deeply trusted by customers from home and abroad.
Main features; 1. Special designed screw, with good plasticizing capacity;
2. Machine is small, investment is low;
3. For professional, so to be outstanding.
Main parameters of the color chips making injection molding machine as below;
| Items | Parameter | Unit | Parameter Value |
| Injection Unit | Screw diameter | mm | 27 |
| Screw L/D ratio | L/D | 19.5 | |
| shot volumn (theoretical) | Cm3 | 48 | |
| injection weight(PS) | g | 44 | |
| plasticizing capacity | g/s | 4.3 | |
| injection rate | g/s | 35 | |
| injection pressure | Mpa | 187 | |
| screw speed | rmp | 170 | |
| Clamping unit | clamp force | KN | 380 |
| open stroke | mm | 235 | |
| space between bars (W*H) | mm | 240*240 | |
| max mould height | mm | 270 | |
| min mould height | mm | 80 | |
| ejector stroke | mm | 60 | |
| ejector force | KN | 17.5 | |
| ejector number | PC | 1 | |
| mould align diameter | mm | 80 | |
| Others | max pump pressure | Mpa | 14 |
| pump motor power | KW | 4 | |
| heating power | KW | 3.2 | |
| machine dimension | m | 2.9*1.0*1.4 | |
| machine weight | T | 1.35 | |
| oil tank capacity | L | 90 |
We make injection molding machines strictly follow ISO9001:2008 quality requirements, per customers's special requirements, CE also can be optional.
We shuangsheng plastic machinery respects staffs and values partnership of each customer, each cooperators, that why we can grow smoothly and steadily even the international ecomonic situation is not so optimistic.
The orgnization chart of our company, average working life of the staffs is 8 years.
Organization Chart
If you have any query about our injection molding machine, just contact me at any time
