Hot sell 1300mm usb driver cutting plotter
Specification
Cutting plotter type |
TH740 |
Kuco TH1300 |
leg |
|
Vertical feeding horse |
|
mainboard |
32 bit CPU, 4 MB CACHE memory at a high speed |
|
Control panel |
Large touch screen and 11 key light touch membrane keyboard |
|
drive |
Dominant twin shaft torque motor, subdivide microstep driver |
|
Feed paper mathod |
Drum high-precision steel shaft |
|
Location mode |
Margin system, setting arbitrary origin |
|
Width of Platform |
740mm |
1300mm |
biggest cutting width |
635mm |
1205mm |
Cutting maximum speed |
500mm/s |
|
Max cutter length |
50000mm |
|
Cutter pressure |
0-1000g(Digital Frequency Control ) |
|
Mechanical Precision |
0.05mm |
|
Accuracy of |
<±0.1mm |
|
Type of cutting tools |
MIMAKI import |
|
Drawing command |
DM-PL/HP-GL (automatic identification) |
|
port |
Stander RS232(string)/USB2.0/SD card |
|
Power supply |
AC110V /220V±10%,50Hz |
|
comsupction |
<100W |
<120W |
Operating enviroment |
tempreture:+5-+35,related humidity30%-70% |
|
Package size |
1045*330*335 |
1582*330*440 |
weight |
18KG |
35KG |
Product highlights:
Standard HPGL language format, more compatibility by using USB interface for data transferring.
Diamond Grade streamlined design, with a luxurious and modern appearance.
Steel sting roller made with Japanese technology which guarantees motion precision.
Advanced optic sensor, automatic 4-point tracking system to check the location points, continuous contour cutting with high resolution.
Compatible software: Flexisign, CorelDraw, Artcut.
Brief Introduce of cutting plotter:
The cutting plotteris a common device in the advertising industry. You can transfer data to the plotterform the computer or by using a USB device (offline working).
USB device on cutting plotter is one of the new technologies promoted by our company. Benefited by such function, people can use a USB FLASH STORAGE instead of a computer to input and output files into the plotter. Using this, can solveall breakdownscaused by the connection between computer and cutting plotter.
Usage:
1.Cut artwork created by yourself , such as sticker,, logos and labels made from vinyl or iron-on material;
2. Can be used to make stickers, transfers, POP signs and graphics, shop signs, window signs logos and graphics;
It is packed in the Standard Carton, put together with install cables, a set of software, cutting blades.
Remark: with plastic package outside when shipping , can keep product dry and clean.
Our office is located in Guangzhou. We have our own factory and technician group. We have
passed CE certification and ISO9000 certification. With the main business of Advertising trade,
.we entered the international market. We have gained a high reputation in China as well as some
overseas areas, like turkey, India, Thailand, Indonesia, Brazil, Kenya, Zambia, Dubai, Australia,
Mexico and so on.
Welcome your inquiry~
