Home > Products > Industry Boiler > High Efficiency Hot Water Boiler
High Efficiency Hot Water Boiler
USD $200,000 - $250,000
/ Set
1 Set(Min.Order)
- 500 Set / Sets per Month
- QINGDAO/SHANGHAI
- T/T
You May Like
- Mini animal feed grinding machine , corn powder hammer mill
- Mini type corn hammer mill , feed grinding machine for sell
- Factory direct sell small feed hammer mill , corn grinding machine
- Large capacity gum arabic hammer mill with cyclone
- Double Win agricultural hammer mill for sale,grain hammer mills for sale
- Ce approval Rice husk hammer mill machine/corn hammer mill/maize grinding hammer mill
Product Details
Condition: | New | Type: | Natural Circulation | Usage: | Other, Industrial, Industry/Power station |
Structure: | Water Tube | Pressure: | Low Pressure | Style: | Other, Horizontal, Packaged/Assembly |
Fuel: | Coal-fired | Place of Origin: | Shandong, China | Brand Name: | HUAYUAN |
Model Number: | SZL-10.5-1.0/115/70 | Output: | Hot Water | Dimension(L*W*H): | 9900*3400*3530mm |
Weight: | 36T | Certification: | ASME | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Hot Water Boiler
Advantages
Parameter List
Boiler type | SZL4.2-0.7/95/70-AII | SZL5.6-0.7/95/70-AII | SZL7.0-1.0/115/70-AII | SZL10.5-1.0/115/70-AII | SZL5.6-0.7/95/70-AII(Q) | SZL14-1.0/115/70-AII | SZL7(0)-1.0/115/70-1.25-AII |
Rated capacity(MW) | 4.2 | 5.6 | 7.0 | 10.5 | 5.6 | 14 | 7(10) |
Rated effuent temperature(°c) | 95(60) | 95 | 115 | 115 | 95 | 115 | 115(94) |
Rated return water temperature(°c) | 70(45) | 70 | 70 | 70 | 70 | 70 | 70 |
Combusion mode | Chain grate | Chain grate | Chain grate | Chain grate | Chain grate | Chian grate | Chain grate |
Applicable coal | AII AIII | AII AIII | AII AIII | AII AIII | AII AIII Gas | AII AIII | AII AIII |
Grate area(m2) | 7.23 | 9.9 | 11.99 | 17.38 | 9.9 | 21.33 | 11.99 |
Heat surface of boiler(m2) | 157.6 | 240.2 | 243.2 | 324 | 240.2 | 440 | 232.3 |
Heated surface of boiler tail(m2) | 174.4 | 236 | 233 | 52.7 | |||
Coal consumption(kg/h) | 896.6(943) | 1186.6 | 1507.6 | 2258 | 1186 | 2938 | 1407(1507.3) |
Exhaust gas temperature(°c) | 175(161) | 175 | 170 | 170 | 175 | 170 | 195(170) |
Dust emission concentration(mg/Nm3) | <80 | <80 | <80 | <80 | <80 | <80 | <80 |
Thermal effciency(%) | 79.2 | 79.59 | 82.17 | 82.3 | 79.59 | 82.5 | 78.28 |
Transfer size(L*W*H)mm | 5370*2970*3550 | 6720*3400*3540 | 8800*3230*2600 | 9900*3400*3530 | 6720*3400*3540 | 10700*3550*3400 | 7570*3230*3540 |
Weight(T) | 36 | 26.4 | 30.51 | 36 | 26.4 | 41 | 33.3 |
Installed size(L*W*H)mm | 8370*5330*3860 | 9000*5000*5600 | 11320*3600*5400 | 13000*4500*5800 | 9000*5000*5600 | 14000*4730*7820 | 11800*4250*5750 |
Rated working pressure(MPa) | 0.7 | 0.7 | 1 | 1 | 0.7 | 1 | 1(1.25) |
FAQ
If you have interests, please contact us with no hesitate.We are sure any of your inquiry will get our prompt reply.If there has a chance,welcome to visit our factory.
Peter Si
Tel: 0086 15244338757
Skype: sichengkun
Whatsup: 0086 15244338757
