QT10-15 block making machine
QT10-15 blocks baking-free brick machine [1] by the loader to sand and gravel and other raw materials into PL1200 batching machine inside the hopper, measured by the electronic meter, according to the computer store by formula ingredients (also can be randomly adjusted), after measuring material from the conveyor into JS750 blender promoted in the hopper, then improve the bucket will be material to the mixer in the bin. Cement, fly ash, etc. At the same time by the screw conveyor to the mixer directly after the above meter measuring cement, fly ash into the mixing chamber, then water will be according to the water cement ratio design flow metering stir in mixing test chamber. Batch after about 3 minutes, 8 m by belt conveyor to the mixing material sent to QT10-15 block the loading points stored inside the hopper. Then the molding machine cloth car will deliver material to the mould, centrifugal force produced by the rotation of shaft fabric would die material forced feeding box, cloth after the completion of the skip returned after a, head down to start working at the same time start the vibrator to vibration pressure of material, molding after box to lift out products then send machine to push the products to send above the brick machine, brick by sending machine after brick surface cleaners cleaning sent to the palletizing machine, and then by the forklift to maintain indoor maintenance.
Technical parameters
1. The machine appearance largest size: 9350 * 2320 * 29500 mm
2. Pressure rated: 21 mpa
3. The main vibration forms: vibration
4. The vibration frequency: 2800-4500 times/min
5. Plate size: 1100 * 900 mm
6. The molding cycle: 15 to 25 seconds/time
7. The total power: 44. 58 kw
