Specifications
QT4-15 Automatic Block Making Machine ,quickly make the block,making the good building material .
QT4-15 Automatic Block Making Machine
No. |
Item |
Quantity |
Unit Price(USD) |
Total price(USD) |
1.Batching system | ||||
01 |
JS500 mixer |
1 set |
5300USD |
6200USD |
02 |
Belt Conveying Machine |
1 set |
900USD |
|
2.Block making machine parts | ||||
01 |
QT4-15C Forming machine |
1 set |
18000USD |
18000USD |
02 |
Pallets Feeder |
1 set |
||
03 |
Brick Conveyor Machine |
1 set |
||
04 |
Hydraulic unit |
1 set |
||
05 |
PLC control unite |
1 set |
||
06 |
Block sweeper |
1 set |
||
07 |
One block mould |
1 set |
Free |
Free |
08 |
Manual unloading cart |
2 sets |
free |
free |
09 |
spare parts and tools |
1 set |
free |
free |
Total price |
24200USD |
|||
Optional parts | ||||
2.Extra Block Moulds | ||||
01 |
Extra block Mould |
1 set |
2300USD |
2300USD |
02 |
Extra paver/interlock mould |
1 set |
2500USD |
2500USD |
Remarks | ||||
01 |
pallets(1010×550×25mm) |
1200pcs |
|
|
Price Terms
1.this price is EXW price
2.Payment terms: 30% as deposit paid by T/T, 70% as the balance paid by T/T or L/Cbefore loading
3.Validity: two weeks
4.Delivery: 30days upon receipt of down payment.
Installation,commissioning and training
If the clients need,1.We will dispatch our technician to install machines, commissioning, and train workers.
2.Installation Fees: US$50.00 per technician per day.
3.Food and Accommodation for installation technicians: at the cost of buyer.
4.Transport fee of our technician (the round-ticket): at the cost of the buyer.
QT4-15C block machine main technical parameters
Dimension of host machine |
3800×1800×2550mm |
Moulding area |
400×800mm |
Moulding period |
15-25S |
The size of the pallet |
1010×550×25/30mm |
Weight of the host machine |
4.6T |
Host machine power |
19.2 KW |
Vibration force |
40KN |
Mixer model |
JD500 |
General water Consumption |
4T/every day |
Voltage |
380V |
Theoretical workshop area : 150m2, need about 6-7workers .the office , curing area and stacking
area to arrange according your fact status..
Production capacity
Size(LxWxH) |
Pcs/Mould |
Pcs/ Hr |
Pcs/ 8 Hr |
|
230×110×70
|
24 |
4320-5040 |
34560-40320 |
|
400X100X200
|
8 |
1200-1920 |
9600-15360 |
|
400X150X200
|
6 |
900-1440 |
7200-11520 |
|
400X200X200
|
4 |
600-960 |
4800-7680 |
|
400X250X200
|
3 |
450-720 |
3600-5760 |
|
Paver:200X100X60
|
16 |
2400-2880 |
19200-23040 |
|
Paver:200X163X60
|
8 |
1440 |
9600 |
We have the right to improve some according the workmanship and technology developing fact .
