Specifications
Overall size 4.6*2*3m (L*W*H)Weight 4.5
Molding cycle 15-18s
Working power 25 kw
Oil station motor 17 kw
QT4-15 block making production line
| ||||||
| ||||||
| ||||||
| ||||||
| ||||||
| ||||||
| ||||||
| ||||||
|
|
Main technical parameters:
1. Aggregate batching plant:
Aggregate batcher is a kind of automatic batching equipment matching with the mixer. It can automatically finish the batching procedures of 3~6 kinds of materials such as sand, stone, cement according to user's design.
2. Wheel loader
3. JS500 concrete mixe
|
Size |
Transportation state: 2*3*4.5m (L*W*H) |
|
|
|
|
Installation state: 2*3*2.9m (L*W*H) |
|
|
|
Weight |
3t |
|
|
|
Working voltage |
380v |
|
|
|
Working power |
43.6 kw |
|
|
|
Mixing motor |
18.5kw |
|
|
|
Hopper lifter motor |
5.5kw |
|
|
|
Water pump motor |
1.1kw |
|
|
|
Reducer motor |
18.5kw |
|
|
|
Mixing cycle |
2 minutes |
|
|
|
Charging volume |
800L |
|
|
|
Discharging volume |
500L |
|
|
|
Production capacity |
25 m3/hr |
|
|
|
|
|
|
|
4. Belt Conveyor Machine (in processing)
5. Block molding machine
- Adoption data transfer device, PLC control system with safe logic control.
- Installing multi-row mixing arms in the unique buggy molding box, when the boxcar moves above the molding box, mixing arms begin to work and add material to the molding box automatically.
- The machine is of multi-functions by changing brick molds, to make various hollow blocks, interlocking blocks, porous blocks, etc. By equipped with color feeder, it can make colorful pavers.
- The imported computer, electric appliances, airtight packing, hydraulic elements used oil pressure and oil motors make this equipment more stable.
Vibration frequency
2500-4500 r/min
Productivity (8 hrs)
400*200*200mm 5,000-6,000 pcs/day
100*200*50mm 12,000-15,000 pcs/day
6. Hydraulic oil Station
8. Stacker machine:
9. hydraulic carts or fork lifter
Block samples/ brick molds:
