Help CenterMDP2002A Three-phase Reference Standard Meter
Related Products
-
MDP2000 Reference Standard MeterUS$ 550 - 950MOQ: 1 Set -
MDP2000A Reference Standard Meters (wide Range)NegotiableMOQ: 1 Set
-
MDP2000 Three-Phase Digital Reference Standard Energy MetersNegotiableMOQ: 1 Set
-
MDP2000 Three-Phase Standard MeterUS$ 1,000 - 2,000MOQ: 1 Set
-
MDP2000 Reference Standard MeterUS$ 550 - 950MOQ: 1 Set
Specifications
1.Accuracy class:0.022.True color LCD display
3.Wide current range:0.1--120A auto shift range
4.Certificate:ISO 9001
Three Phase standard energy meter
1.class accuracy:0.02
2.Adopts latest DSP technology,intelligent processing
3.Complete digital technology,four quadrant reactive/active measurement.
4. With LCD display and error calculator
5.Three phase energy,voltage,current, power measurement and frequency,power factor,error
calculation etc functions.
6.RS232 communication port,PC software is available for more functions.
7. Phase measurement:0-359.99deg, adjusting resolution 0.01deg,accuracy class 0.05deg
8.Frequency measurement:45-65HZ resolution:0.01HZ
9.Voltage ranges:3*60V,3*100V,3*200V,3*400V, current ranges:0.1A,0.25A,0.5A,1.0A,2.5A,5A,10A,20A,40A,100A
10.Power supply:AC220V+/-10%,50+/-10%HZ
nnect mode: 1P2W,3P3W( active,reactive-true,reactive-accross,reactive-accross60/90),3P4W(active, reactive-true)
