SH15 Single Phase Multifunction Onsite Portable Energy Meter Calibrator

19 years of professional experience

low price and excellent quality

stantard of ISO9001 ,IEC

excellent after-sales service

highly customizable

SH15 Onsite Single phase meter test instrument

The main features:

1-Special plastic mould case, light weight and easy for portable, LCD display

2-Measure voltage, current, power . phase power factor without disconnecting power

circuit

3-Test positive /negative error of sigle phase meter without disconnecting power circuit

4-Wide current clamp rang :0.5-100A

5-Wide working voltage rang : AC180 - 250V

6-Power supply directly supplied by voltage testing wire

7-High and low frequency energy pulse output.Easy to send and test

8-sampling by scanning head, directly input pulse of electronic meter or manual switch calibration

9-Can be connected with the external current load box and support the simulated load

Performance index

1.      voltage measured scope: AC110-260V, accuracy:0.3%

2.      Voltage measured scope:AC0.5-100A, accuracy : 0.3%

3.      Phase scope:0°- 360° .accuracy:±1.0°

4.      Power measured accuracy : 0.3class Energy measured accuracy :0.3class

5.      Power comSumption 3VA

6.      weight :0.3kg

7.      Dimension: 185mmx80 x41mm

8.      working circumstance : temperature-10°- +45°; relative humidity:20%- 90%

1. Packing & Shipping

      Packed in Plywood case

      Deliver the goods within one month after receiving the prepayment

 1. We can produce the single phase meter test bench/single phase energy meter instrument/single phase electricity meter test equipment according to client's requirement.

  2. Good after-sale service, and good quality.

  3.  All our products can test all items such as Per IEC and ANSI

 1.  What is the advantages of your products?

        Thanks for your inquiry. Our products' advantages is that all products achieve the standard of IEC and ANSI.

        And our goods have been exported to many countries in the world, such as Korea, India, Russion, Pakistan, Vietnam ans     so on. The quality is excellent that it wins lot reputation for us.

   2.   What is the shelf life for your products?

         Thanks for your consideration. The shelf life of our products is 3 years. (Our company is responsible for the repairing and maintaining free of charge)

   3.   What terms of trade your company accept?

         Thanks for your consideration. Our company accepts T/T, L/C, Western Union. Thanks for your understanding.
