Specifications
1. Portable meter tester onsite2. Test meter errors without disconnecting mains supply
3. ISO9001 verified
Portable meter tester onsite
The main features:
1-Special plastic mould case, light weight and easy for portable, LCD display
2-Measure voltage, current, power . phase power factor without disconnecting power
circuit
3-Test positive /negative error of sigle phase meter without disconnecting power circuit
4-Wide current clamp range:0.5-100A
5-Wide working voltage range: AC180 - 250V
6-Power supply directly supplied by voltage testing wire
7-High and low frequency energy pulse output.Easy to send and test
8-sampling by scanning head, directly input pulse of electronic meter or manual switch calibration
9-Can be connected with the external current load box and support the simulated load
Performance index
1. voltage measured scope: AC110-260V, accuracy:0.3%
2. current measured scope:AC0.5-100A, accuracy : 0.3%
3. Phase scope:0°- 360° .accuracy:±1.0°
4. Power measured accuracy : 0.3class Energy measured accuracy :0.3class
5. Power comSumption 3VA
6. weight :0.3kg
7. Dimension: 185mmx80 x41mm
8. working circumstance : temperature-10°- +45°; relative humidity:20%- 90%
