Help CenterDZ603-6 Three Phases Energy Meter Test Equipment
Related Products
-
DZ603-12 TypeThree Phase Energy Meter Calibration Test BenchUS$ 5,000 - 50,000MOQ: 1 Set -
Three Phase Watt Meter Test BenchUS$ 5,000 - 50,000MOQ: 1 Set
-
DZ601-24 Single Phase Meter Test BenchNegotiableMOQ: 1 Set
-
DZ603-6 Three Phase Energy Meters Test EquipmentsNegotiableMOQ: 1 Set
-
DZ601-12 Single Phase Energy Meter Test BenchNegotiableMOQ: 1 Set
Specifications
1. Test all items as per IEC and ANSI2. Certificate: ISO 9002
3. Accuracy class: 0.05
4. Excellent aftersale service
DZ603-6 Three Phases Energy Meter Test equipment
Main Performance:
1. Shall carry out completely automatic calibration items such as running with no load, starting, basic error, standard distortion and 24 hours variation etc according to testing regulations: four quadrant: positive, negative, active or reactive error test, automatic shift the input of all kinds of pulse.
2. The tested meters maybe same specification but different communication protocols.
3. Shall carry out tests such as demand cycle and its display, time interval error, register combined error and daily error.
4. Communication test, GPS broadcast time calibration, meter data verification, regarding record meter number.
5. According to regulations, carry out various influence value test, voltage falling and interruptions shall be carried out.
6. Automatically adjust black spot, calculate time for starting test and running with mo load test according to regulations.
7. Shall adopt fixed time and fixed quality burden methods to carry out the reading test, and different time interval with different burden tests are available.
8. Shall display the voltage and current wave diagram with same phase: shall set and measure 2~21 times harmonic wave and measure the distortion degrees.
9. Data be processed and printed automatically, and the table lay out shall be set freely according to user's requirements, transfer data by all M2S port.
10. Support: bar code input, error curve, error limit setting, multi-mode calibration plans and equipment management authority etc.
Technical Index:
item |
Class 0.1 |
Class0.05 |
|
Equipment accuracy class |
0.1 for active 0.2for reactive |
0.05 for active 0.1 for reactive |
|
Standard meter accuracy class |
0.05 |
0.02 |
|
Voltage isolated transformer accuracy class |
0.01 |
0.01 |
|
Current range |
0.1A 0.5A 1.0A 2 .5A 5A 10A 50A 100A |
||
Voltage range |
57.7V 100V 220V 380V |
||
Output power |
voltage |
180VA/phase |
|
Current |
240VA/phase |
||
Voltage adjusting |
Adjusting range |
0~120% |
|
Adjusting resolution |
10% 1% 0.1% 0.01% 0.001% |
||
Current adjusting |
Adjusting range |
0~120% |
|
Adjusting resolution |
10% 1% 0.1% 0.01% 0.001% |
||
Phase adjusting |
Adjusting range |
0.00°~359.99° |
|
Adjusting resolution |
10° 1° 0.1° 0.01° |
||
Frequency adjusting |
Adjusting range |
45.00~65.00Hz |
|
Adjusting resolution |
10Hz 1Hz 0.1Hz 0.01Hz |
||
Waveform distortion |
<0.5% |
||
Three phase dissymmetry |
<0.5° |
||
Power stability |
<0.05 |
||
|
Display Accuracy class |
Voltage |
±0.3% |
|
Current |
±0.3% |
||
power |
±0.3% |
||
frequency |
± 0,02Hz |
||
phase |
<0.2° |
||
Working power |
220V±10% 50Hz |
||
1. Packing & Shipping
Packed in Plywood case
Deliver the goods within one month after receiving the prepayment
1. We can produce the single phase meter test bench/single phase energy meter instrument/single phase electricity meter test equipment according to client's requirement.
2. Good after-sale service, and good quality.
3. All our products can test all items such as Per IEC and ANSI
1. What is the advantages of your products?
Thanks for your inquiry. Our products' advantages is that all products achieve the standard of IEC and ANSI.
And our goods have been exported to many countries in the world, such as Korea, India, Russion, Pakistan, Vietnam ans so on. The quality is excellent that it wins lot reputation for us.
2. What is the shelf life for your products?
Thanks for your consideration. The shelf life of our products is 3 years. (Our company is responsible for the repairing and maintaining free of charge)
3. What terms of trade your company accept?
Thanks for your consideration. Our company accepts T/T, L/C, Western Union. Thanks for your understanding.
