Home > Products > GRADING SIEVES > china high quality grain prowder vibrating screen for sale
china high quality grain prowder vibrating screen for sale
- 100 Set / Sets per Month
- Qingdao/Shanghai/other port
Product Details
Condition: | Used | Year: | 2016.1.1 | Type: | Circular |
Application: | Other, classifiter | Place of Origin: | Henan, China | Brand Name: | senyou |
Model Number: | sy-800 | Voltage: | 220V/380V | Power(W): | 1.5kw |
Dimension(L*W*H): | 1150*1150*1200 | Weight: | 100kg | Certification: | ISO9001:2008 |
Warranty: | 12 Months | After-sales Service Provided: | No overseas service provided |
Product Description
Specificatio
china high quality grain prowder vibrating screen for sale
(1) Less or no net-cleaning time.
(2) No assistant objects bring pollution to the powder body e.g. rubber ball.
(3) Keep the size of mesh precise and make the sieving precision stable.
(4) Disassemble the adhesion objects and reduce left material on the mesh.
(5) High screening efficiency.
(6) Processing material size 0~600 mesh.
china high quality grain prowder vibrating screen for sale
Product Introduction
ultrasonic vibrating screen for fine powder , eliminates the blinding and blocking of mesh. It has
revolutionized the screening of difficult powders on sieve meshes, allowing accurate
separation down to 25 microns. It also increases screening capacities and reduces mesh
breakage.
This ultrasonic system has been designed so that it can be retrofitted onto any new or
existing vibrating sieve/separator, which is called SY ultrasonic vibrating sieve.
Working principle
Its vertical motor, which is installed eccentric hammers on the top and bottom, is regarded as a vibratory source. The eccentric hammers change rotation into horizontal, vertical and inclined movement, and then pass the movement to the sieving surface. Adjusting the phase angle on the top and bottom can change trajectories of the materials on the sieve.
Features
1.High screening accuracy circular Sieve Shaker
2.High efficiency powder Sieve Shaker
3.Appropriate for any power ,grain ,mucus
4.Compact structure without any dead angles
5.Easy to clean and disinfect thoroughly
6.New net frame, long use life of screen, change the sieve easily
7.Can be used in single layer and multilayer screens
8. Frames can be 360 adjusted arbitrarily, suitable to apply in the production line
9.Spare parts are made of stainless steel
10.The materials discharge automatically ,can work continuously
Structure
Technical Parameters
Model | Power (kw) | Diameter of screen (mm) | Dimension (mm³) |
SYD-600-S | 0.25-0.55 | 550 | 800*800*750 |
SYD-800-S | 0.55-0.75 | 760 | 900*900*750 |
SYD-1000-S | 0.75-1.50 | 930 | 1160*1160*810 |
SYD-1200-S | 1.10-1.75 | 1130 | 1360*1360*885 |
SYD-1500-S | 1.50-2.20 | 1430 | 1850*1850*990 |
Parts Show
Application
Delaminated sand screening machine for powder sieving is widely used in:
1) Chemical industry: resin pigment, medicine, grease, paint, palette, etc.
2) Abrasive material and ceramic industry: building sand, mica, alumina, abrasive, refractory material, slurry, etc.
3) Food industry: sugar, salt, alkali, gourmet powder, starch, milk powder, yeast powder, pollen, food additive, bean milk, juice, etc.
4) Papermaking industry: coated slurry, exhaust liquid, paper making liquid and waste water reclamation, etc.
5) Metallurgy and mining industry: quartz sand, ore, titanium oxide, zinc oxide, etc.
6) Mechanical industry: casting sand, powder metallurgy, electromagnetic material and metal powder, etc.
Packaging & Shipping
Packaging
Export wooden case
Waterproof,anti-corrosion,difficult to burn,sturdy and durable.
Delivery Detail
Adequate stock,delivery in 10 days after payment.
Company Information
Xinxiang Senyou Mechanical And Electrical Co. Ltd., is a technological ceramic-machinery enterprise created by a team of long time ceramics engineers.Senyou makes every effort to produce multi functional machines with modern design, and high practicability &reliability,there is great innovation in our products, therefore Senyou wins a wide favors from customers.
Senyou offers the widest range of sieving and filtration equipment for ceramic,mainly produces“WINERIS”slurry vibrating sieve,drum vibrating sieve,flat vibrating sieve, high-frequency glaze vibrating sieve,dry-powder vibrating sieve,etc.
With our extraordinary confidence,stable high quality and client-ease service,we believe Senyou will create a new prosperity in the China ceramic machineries industry.
Our Factory
We are a professional manufacture of screening equipment supplier, who has advanced mechanical and manufacturing engineer and senior mechanics. Their average working experience is more than 10 years. We are focus on quality, innovation and devote ourselves to technology development all the time. With the professional technical teams and richly manufacturing experience, we can supply excellent vibrating machines for global customers.
