commercial flour sifter/sifter/electric vibrating sand screen for rice,grain,sugar

Application:

Food industry: flour, milk powder, starch, rice flour, seasoning, fruit juice, granulated sugar, etc.

Chemical industry: PVC resin powder, citric acid, Polyethylene powder, washing powder, etc.

Pharmacy industry: Kinds of medicinal powder.

Metallurgy: quartz sand, black lead, alumine and other powders.

Structure and characters:

1.The main part is stainless steel, and the base can be carbon steel or stainless steel.

2.Outlet can be adjusted

3.Convenient in moving

4.Kinds of wire screen mesh size to choose.

5.High precision screening and filtering

6.Compact structure, little dust, low noise and low energy consumption.

Working principle - SENYOU

Its vertical motor, which is installed eccentric hammers on the top and bottom, is regarded as a vibratory source. The eccentric hammers change rotation into horizontal, vertical and inclined movement, and then pass the movement to the sieving surface. Adjusting the phase angle on the top and bottom can change trajectories of the materials on the sieve.

Structure - SENYOU

Feature - SENYOU

• No Clogging of Screen

As the screen vibrates in multiplane hence the holes of the screen remain clear. Additional and blinding system is provided for difficult to screen and wet materials.

• Minumum blinding of screens

 Due to vibrations in the vertical plane, blinding of screen is minimized. However, for certain materials which have inherent blinding, sticking property and special accessories can be used to eliminate this problem.

• Low on power and maintainence / High on efficiency

 The design enables to utilize the vibratory force generated by the motor to the optimum and very few moving parts reduce the maintenance to minimum.

•  Multiple separations

As many as five screens could be mounted on one separator achieving six sizes materials to get.

• Optimum space / capacity

 This separator achieves greater production, separation per unit of screening area as compared with any other screening method or device.

• Pollution free /Clean operation

 Because of the little input mouth,The whole operation is very clean and pollution free.

Technical parameters - SENYOU

Application - SENYOU

Electronic power spin vibrator sieve is widely used in:
1) Chemical industry: resin pigment, medicine, grease, paint, palette, etc.
2) Abrasive material and ceramic industry: building sand, mica, alumina, abrasive, refractory material, slurry, etc.
 3) Food industry: sugar, salt, alkali, gourmet powder, starch, milk powder, yeast powder, pollen, food additive, bean milk, juice, etc.
 4) Paper-making industry: coated slurry, exhaust liquid, paper making liquid and waste water reclamation, etc.
5) Metallurgy and mining industry: quartz sand, ore, titanium oxide, zinc oxide, etc.
 6) Mechanical industry: casting sand, powder metallurgy, electromagnetic material and metal powder, etc.
