2.0-2.6ton Wheel Loader N926 With Weichai Power HUAFENG/Yuchai/YTO Engine for Africa Markets

2.0-2.6ton Wheel Loader N926 With Weichai Power HUAFENG/Yuchai/YTO Engine for Africa Markets photo-1
US$ 9,800 - 22,800 MOQ: 1 Unit
Key Specifications
Get Latest Price
Condition:
New
Brand Name:
ZOT
Model Number:
N918
Payment & Shipping
Payment Methods:
Port of Shipment:
qingdao china
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Brand Name ZOT
Model Number N918
Place of Origin Shandong, China
Type Front Loader
Moving Type Wheel Loader
Dimension(Long * Breadth * High) 4550/1820/2550mm
Rated Load 1TON
Certification GOST,CE,ISO
Warranty 12MONTHES
After-sales Service Provided Engineers available to service machinery overseas

Specifications

with WEICHAI power,huafeng diesel engine.4wheels driving.
truck model clutch gearbox,or torque convert and gearbox assembly.

N926 SMALL WHEEL LOADER



 PRICE:8500-12800USD per unit EXW

Features:
1. small wheel loader uses the inline. Direct injection, water-cooled, four-stroke engine with excellent cod start performance. Powerful energy. Reliable function and efficient energy saving.
2. small wheel loader Motor is US Eaton. Ensure the good performance.
3. Full hydraulic drive system. Low consumption drive. Stable and simple operation, 2 gear hydraulic variable speed changes.
4. The streamline design makes the appearance attractive and modern.
5. The driving cab uses hardened molding glass with broad view and more safe.
6.  small wheel loader has flexible link and is equipped with new daCSboard and adjustable steering column. Which can reduce vibration and make the operation convenient and comfortable.
7.  small wheel loader has quick change system. Can change the front part very fast.  Manual quick change system. Very easy. One man can operate.
8. Hydraulic brake system, Drum brake.



Technical specificaitons

Rated load

2000kgs

Bucket capacity

0.9-1.2m3

Unload height

2262mm

Unloading Clearance

741mm

Max tractiv force

35kN

Kerb weight

2690kg

Turning Angle

35°

Mini Turning Radius

3879 mm

Ground Clearance mm

240 mm

Engine

changchai/FAW/HUAFEI WEICHAI POWER

Transmission

GEARBOX AND TORQUE CONVERT.

Speed



Forward I

0 - 7 km/h

Forward II

0 - 18 km/h

Reverse I

0 - 7km/h

Reverse I

0 - 14 km/h

Working Hydraulic Pressure

22Mpa

Lifting time

4s

Lowering time

3.5s

Three cycle time

9s

Tyres

131x15.5-15

(Length*width*height)mm

4880/1850/2850mm

tread

1660 mm

wheel base

1810 mm

 2.0-2.6ton wheel loader N926 with weichai power HUAFENG/Yuchai/YTO engine for Africa markets2.0-2.6ton wheel loader N926 with weichai power HUAFENG/Yuchai/YTO engine for Africa markets2.0-2.6ton wheel loader N926 with weichai power HUAFENG/Yuchai/YTO engine for Africa markets2.0-2.6ton wheel loader N926 with weichai power HUAFENG/Yuchai/YTO engine for Africa markets2.0-2.6ton wheel loader N926 with weichai power HUAFENG/Yuchai/YTO engine for Africa markets
