Help CenterChina CE910 1.0ton Loader With Yanmar E3 Engine Pilot Control,joystick,quick Coupling for Eurozones
Related Products
-
CHINA 2.0t Mini Wheel Loader ZOTNegotiableMOQ: 1 Set -
China 1.2t Mini Wheel LoaderNegotiableMOQ: 1 Set
-
China CE910 1.0ton Mini Loader With Yanmar E3 Engine Pilot Control,joystick,quick Coupling for EurozonesUS$ 6,000 - 12,800MOQ: 1 Unit
-
3.0t Wheel Loader T930 China SDLG Cummins EngineNegotiableMOQ: 1 Set
-
China 1.8t Mini Wheel Loader T918C Zot Wheel LoaderNegotiableMOQ: 1 Set
Specifications
1.with yanmar or xinchai E3 engine,2.Pilot control,Quick coupling,
3.different attachments,fork,grapple,snow blade,blowers.CE
CE910 MINI WHEEL LOADER(CE)
WITH XINCHAI E3 OR YANMAR E3 DIESELE NGINE.
JOYSTICK CONTROL,QUICK COUPLING
3RD OR 4TH FUNCTIONS
ATTACHMENTS:FORKS,MOVERS,GRAPPLERS,SNOW BLADES,SNOW BLOWERS.
PRICE:6000-12800usd per unit FOB china port.
Warranty:12monthes after shipping.
Features:
1. CE910 small wheel loader uses the inline. Direct injection, water-cooled, four-stroke engine with excellent cod start performance. Powerful energy. Reliable function and efficient energy saving.
2. CE910 small wheel loader Motor is US Eaton. Ensure the good performance.
3. Full hydraulic drive system. Low consumption drive. Stable and simple operation, 2 gear hydraulic variable speed changes.
4. The streamline design makes the appearance attractive and modern.
5. The driving cab uses hardened molding glass with broad view and more safe.
6. CE910 small wheel loader has flexible link and is equipped with new daCSboard and adjustable steering column. Which can reduce vibration and make the operation convenient and comfortable.
7. CE910 small wheel loader has quick change system. Can change the front part very fast. Manual quick change system. Very easy. One man can operate.
8. Hydraulic brake system, Drum brake.
Technical specificaitons
Rated load |
1000kgs |
Bucket capacity |
0.6m3 |
Unload height |
2262mm |
Unloading Clearance |
741mm |
Max tractiv force |
35kN |
Kerb weight |
2690kg |
Turning Angle |
35° |
Mini Turning Radius |
3879 mm |
Ground Clearance mm |
240 mm |
Engine |
Chinese xinchai EIII diesel, 4 cylinders, direct injection,25.2 kW/34.3HP/2200rmp, displacement 2.19l |
Transmission |
Hydrostatic transmision . 4WD Fully hydraulic drive .2 gear hydraulic variable speed changes |
Speed |
|
Forward I |
0 - 7 km/h |
Forward II |
0 - 24 km/h |
Reverse I |
0 - 7 km/h |
Reverse II |
0 - 24 km/h |
Working Hydraulic Pressure |
22Mpa |
Lifting time |
4s |
Lowering time |
3.5s |
Three cycle time |
9s |
Tyres |
131x15.5-15 |
(Length*width*height)mm |
4113/1520/2350mm |
tread |
1160 mm |
wheel base |
1710 mm |
