Copper Conductor Material and PE Jacket Control cable
Model, Name and Main Application
Model | Name | Main Applications |
KVV | Copper Conductor PVC insulated and sheathed control cable | For Laying indoors, in trenches and in ducts, For fixed installation |
KVVP | Copper Conductor PVC Insulated &sheathed copper wire braiding screened control cable | |
KVVP2 | Copper Conductor PVC insulated &sheathed control cable with copper tape shield | |
KVV22 | Copper Conductor PVC insulated and sheathed control cable with steel tape armor | For laying indoors, in trenches, in ducts and in ground, able to withstand heavier mechanical force, and for fixed installation |
KVVR | Copper Conductor PVC Insulated and sheathed flexible control cable | For laying indoors, movable and flexible |
KVV32 | Copper Conductor PVC insulated and sheathed control cable with steel wire armor | For laying indoors, in trenches, in ducts and in ground, able to withstand heavier mechanical force, and for fixed installation |
ZR-KVVRP | Copper Conductor PVC insulated &sheathed copper wire braiding screened flexible control cable flame retardant | Fixed laying indoors with capability of moving and screening |
ZR-KVV | Copper conductor PVC insulated and sheathed flame retardant control cable | For laying indoors, in trenches, in ducts, and for fixed installation. The cable should be flame retardant |
ZR-KVVP2 | Copper Conductor PVC insulated and sheathed flame retardant control cable with steel tape armor | |
ZR-KVV22 | Copper Conductor PVC insulated &sheathed flame retardant control cable with steel tape armor | For laying indoors, in trenches, in ducts, and underground. The cable should be flame retardant and able to bear heavier mechanical force, and for fixed installation |
ZR-KVVR | Copper conductor PVC insulated and sheathed flame retardant flexible control cable | For laying indoors, and the cable should be flame retardant flexible and movable. |
ZR-KVV32 | Copper Conductor PVC insulated and sheathed flame retardant control cable with steel wire armour | For laying indoors, in trenches, in ducts, and underground, the cable should be flame retardant and able to bear beaver extermal mechanical force, and for fixed installation |
Specification |
1.Rated voltage: 450/750V 2. Standard applied: IEC 60227, BS 6004, VDE 0281, JB/T8734 3. Max. working temperature: 70 °C ,can be 90 °C ,105 °C and 125 °C as per requirement 4. Insulation: PVC,LSOH material 5.Number of cores: multi-core for this type of cable 6.Cross sectional area: 2*0.75mm2 to 61*2.5mm2 available 7.Cable color: red,black,green and yellow and so on 8. Packing: 100M/roll, as per customer's requirements 9. Quality certificate: CCC 10.OEM and customize can be available |
1. By export standard rolls or drums
2.The length and package can be followed by the customer's requirement
Pre-sale service -----Offering hot-line for product and technical consultation Offering specified project design to meet the clients’ demand.
During-sale service----Offering training on application instruction, supervising installation condition, and debugging.
After-sale service------ Offering 24-hour service, product upgrading or alteration, and other service.
Other type power cable
Certifications:
Q1:When can I get the price?
We usually quote within 6 hours after we get your inquiry. If you are very urgent to get the price, please call us or tell us in your e-mail so that we will regard your inquiry priority.
Q2.How can I get a sample to check your quality?
After price confirmation, you can require for samples to check our quality. Sample is free, but the freight charge should be paid.
Q3.How long can I expect to get the sample?
After you pay the freight charge and send us confirmed files, the samples will be ready for delivery in 3-7 days. The samples will be sent to you via express and arrive in 3~5 days.
Q4.What about the lead time for mass production?
Honestly, it depends on the order quantity and the season you place the order.The best record we keep is delivering 10 kilometers cable within a week. Generally speaking, we suggest that you start inquiry two months before the date you would like to get the products at your country.
Welcome your inquiry of control cable! We will reply you within 12 hours!
