This tester test stretching resistance, drawing force, compression strength, bending resistance, extensibility,etc.YL-1123 Universal Material Tester
Purpose:
Universal Material Tester is designed for test strength of various materials, finished products, semi-finished products and monocase, select various clamps and smelt tool, can do test of stretching resistance, drawing force, compression strength, bending resistance, extensibility, tearing, peeling, stress, strain, shearing force, etc.
Features:
Clorful liquid crystal display, light touch switch;
Cnnected computer can obtain point, and conduct various data analyses, printout.
Software has powerful functions, suitable used for the industries of metal, steel products, aviation, rubber plastic, cable, shoes, leather, chemicals and so on.
Specifications:
|
Capacity Option |
5,10,20,50,100,200,500,1000,2000KG (select one kind) |
|
Force Resolution |
1/250,000 |
|
Force Accuracy |
≤±0.5% |
|
Stroke Resolution |
0.005mm |
|
Test Stroke |
700mm, without grips |
|
Test Width |
350mm |
|
Test Speed |
0.5-500mm/min |
Force Unit Switch |
Ton,Kgf,g,N,kn,lbf,TON (switchable) |
Stop Method |
Overload Stop, specimen damage stop, emergency stop button, upper & lower limit stop, over stroke protection |
Control Method |
All computerized operation control |
Machine Dimension |
95×58×151 cm(W×D×H) |
Machine Weight |
140KG |
Power |
AC 220V , 50/60HZ, 4A |
Standard Device |
One set of grips, computer software, computer connection wire, one set of software CD. |
