Natural Leather Tearing Strength&Tension Tester (YL-1102)

Name: Natural Leather Tearing Strength&Tension Tester (YL-1102)
Brand: Yuelian
SKU: 112424347
Availability: InStock

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

Yuelian

Model Number:

YL-1102

Guangdong Yuelian Instruments Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name Yuelian

Model Number YL-1102

Power Other, Electronic, 1 HP, AC 220V, 50/60 Hz, (10A) or specify

Usage Tensile Testing Machine

Natural Leather Tearing Strength&Tension Tester(YL-1102)

This tester is used to test compression resistance intensity for bottle of food processing industry and other packaging industries.

Specification:

Capacity	1,2,5,10,20,50,100,200kg
Unit Switch	kgf , lbf, N , kN
Testing Item	compression resistance intensity, compression resistance deformation, constant compression (pulling) testing, tearing strength, tensile strength.
Testing Accuracy	<±0.1%;
Force Resolution	1/10,000
Valid Range of Strength Test	1~100%F.S
Deformation Value Accuracy	Precede±1.0%
Range of Speed test	50~600mm/min, Available Set Free
Test Stroke	650mm without grip
Test Space	140mm
Force Unit Switch	kgf, gf , N, kN, Ibf
Stress Unit Switch	MPa,kKPa,kgf/cm2,Ibf/in2
Deformation Unit Switch	mm,cm,in
Stop Mode	Upper & lower limit security setting, emergency stop button, force&stretching setting, specimen damage sensor
Machine Weight	Approx 55kg
Motor	DC motor
Power	1PH, AC 220V,50/60Hz, 10A or specify
