martindale abrasion and wear tester(YL-3315M4)
Purpose:
4 Digits Martindale Abrasion and Wear Tester martindale abrasion and wear tester for leather, textile applicable to performance test of abrasive test and appearance changes(pilling) test for textile, artificial
leather, synthetic leather and film material with pressure.
Standards:
GB/T21196-2007, GB/T13775, FZ/T20020, ASTM D3886, JIS L1096, IWS, TM196, TM112, M&S GB/T4802.1-1997, ASTM D4970, ISO12945-2
Specification:
Workstation |
4 digits (available to choose 8 digits machine) |
Timer |
0~999999 times |
Maximum Stroke |
crosswise: 60.5±0.5mm |
Length ways |
24±0.5mm |
Weight of pressing object |
a. gripper: 200±1g |
Abrasion Block effective friction diameter |
Type A 200g(1.96N) Friction head(9KPa) 28.8 -0.084mm |
Relative motion speed of gripper and machine |
50-2r/min |
specimen Pressure hammer weight |
2385±10g |
Machine dimension |
885×600×410mm |
Power |
AC 220V 50Hz 500W |
Weight |
67kg |
