Martindale Abrasion Resistance Tester

Name: Martindale Abrasion Resistance Tester
Brand: Yuelian
SKU: 112422983
Availability: InStock

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

Yuelian

Model Number:

YL-3315M

Guangdong Yuelian Instruments Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name Yuelian

Model Number YL-3315M

Power Electronic

Usage Leather Testing Instrument

Martindale abrasion resistance tester(YL-3315M)

Purpose:

Martindale abrasion resistance tester applicable to performance test of abrasive test and appearance

changes(pilling) test for textile, artificial leather, synthetic leather and film material with pressure.

Standards:

GB/T21196-2007, GB/T13775, FZ/T20020, ASTM D3886, JIS L1096, IWS, TM196, TM112, M&S GB/T4802.1-1997, ASTM D4970, ISO12945-2

Specification:

Workstation	4 digits (available to choose 8 digits machine)
Timer	0~999999 times
Maximum Stroke	crosswise: 60.5±0.5mm
Length ways	24±0.5mm
Weight of pressing object	a. gripper: 200±1g b. apparel fabric specimen heavy punch: 395±2g c.furnishings specimen heavy punch: 594±2g d. Stainless steel lamination: 260±1g
Abrasion Block effective friction diameter	Type A 200g(1.96N) Friction head(9KPa) 28.8 -0.084mm Type B 155g(1.52N) Friction head(12KPa) 90 -0.10mm
Relative motion speed of gripper and machine	50-2r/min
specimen Pressure hammer weight	2385±10g
Machine dimension	885×600×410mm
Power	AC 220V 50Hz 500W
Weight	67kg
