Salt Spray Corrosion Test Chamber / Salt Mist Testing Carbinet / Salt Fog Testing Equipment / Salt Spray Corrosive Test Machine
- 100 Set / Sets per Month
- Shenzhen
- T/T L/C D/P D/A Credit Card PayPal
Product Details
Place of Origin: | Guangdong, China | Brand Name: | Yuelian | Model Number: | YL-2208B |
Power: | Electronic | Usage: | Other, salt spray tester |
Product Description
Salt spray corrosion test chamber/Salt mist testing carbinet/Salt fog testing equipment/ Salt spray corrosive test machine is one of high quality products in our company.
Materials used:
1.Test chamber: use the PVC gray impact resistance plate (from Germany), 5mm in thickness;
2.Thermostat water tank: use the gray impact resistance plate of PVC (from Germany), 5mm in thickness
and it is equipped with the auto water level controller to avoid the inconvenience to refill the water by
manpower.
3.The upper cover of the test chamber: use the European transparent acrylic plate, 5mm in thickness;
4.The barrel for refilling the reagent: equipped with a built-in water level gauge. Use the gray impact
resistance plate made of PVC,5mm in thickness, which looks as an integral whole with the machine stand.
5.The basket supporter inside the test chamber: use the gray PVC impact resistance plate, the test angle
can be freely adjusted to 15º and 30º
a)48 test pieces can be placed by the angle of 15 degree
b)30 test pieces can be placed by the angle of 30 degree
Note:the size of the test pieces is 150×70mm(H×D)
6,The saturated air tank: made of stainless steel, 2mm in thickness and equipped with the auto water level
controller to avoid the inconvenience to refill the water by manpower.
Design standard:
CNS 3627, 3885,4159,7669,8866;
JIS D-0201,H-8502,H-8610,K-5400,Z-2371;
ISO 9227, 3768, 3769,3770;
ASTM B-117, ASTM B-268, B-268
GB-T2423,GJB150, GB10587-89, GB 2423-17, IEC68-2-11
Safety devices:
1.Water level controller 1set
2.State warning lamp 3pcs
3.Protection switch for over temperature 2 sets
Application Temperature:
1.The test method of salt water. The test chamber: 35°C±1°C/ The saturated air barrel: 47°C±1°C
2.The test method of corrosive resistant. The test chamber: 50°C±1°C/The saturated air barrel: 63°C±1°C
Spraying modes:
1.Conical disperser: It can adjust the spraying and make the reek and falling reek even.
2.Nozzles(Taiwan): Glass nozzles. The accurate glass nozzles (self-made)
Note:volume of spraying: 1~2 mL/80CM2/1h(self-made)
Accessories:
1. Bracket for 1 set(can carry the weight of test samples under 2kgs).
2. 500g Nacl reagent contained in 2 bottles(contained in 4 bottles for standard type)
3. 10kg barrel for salt water making 1pc.
4. 80cm2 standard collecting cup 1pc.(2pcs. for standard type)
5. 50ML graduated cylinder 1pc.(2pcs. for standard type)
6. The detailed operational manual and standard documentation.
