Thermal shock/thermal shock test chamber/thermal shocking testing machine(S3-80-55C)
Application:
Thermal shock is similar to noncontinuously being low temperature or high temperature; thermal shock tester can make various products accomplish test in shortest time. Chemical change or physical injury made by heat shock is caused by thermal expansion and contraction change or other physical nature change; use TST system to achieve entire trust for various products. Effect of heat shock is including finished products cracked or broken layer, and electrochemical change caused by replacement. All-digital automatic control of TST system makes you easy and handy operation.
Note: a 80L thermal test chamber is in the factory. Pack it with film to avoid dust.
Feature: 3 cabintes(one is for cold air, one for hot air, while the middle area is the space for thermal shock tests. ); 2 cabinets(hot air and cold air.)
Specification:
Model No. |
S3-80 |
S3-150 |
S3-250 |
S3-450 |
|
Interior Dimension (cm) |
50×40×40 |
60×50×50 |
70×60×60 |
80×75×75 |
|
Exterior Dimension (cm) |
172×200×147 |
182×210×157 |
192×220×167 |
202×238×185 |
|
Temperature Range of Test Area |
High temperature: +60~+150 celsius degree; Low temperature: -10 ~ -65 celsius degree A. -40 B. -55 C. -65 |
||||
High Temp. Area Heating Time |
RT200 approx 30min |
||||
Low Temp. Area Cooling time |
RT-70 approx 90min |
||||
Temp. Recover Time |
Within 5min |
||||
Temp. Stability |
±0.2 celsius degree |
||||
Insulation Material |
Thermostability,high density amino acid ethyl ester foam insulation material |
||||
System |
P.I.D+S.S.R+ microcomputer balance thermostat control system(Japan) |
||||
Refrigeration System |
Semi-sealing two-stage compressor (water-cooling style) |
||||
Protection Device |
Breaker, compressor high&low pressure protection switch, refrigerant pressure protection switch, failure warning system, electronic siren |
||||
Accessories |
2 pcs of upper and lower adjustable interlayer |
||||
Power |
Single phase, 220V, AC±10% 50/60Hz&3 phase, 380V/415VAC±10% 50Hz |
||||
Weight (Approx) |
1550kg |
1680kg |
1900kg |
2480kg |
|
Certificate:
Exhibition:
Factory:
