Home > Products > New Products > Factory Price 600Kva Silent Generator, Powered by Cummins KTA19-G8 Engine
Factory Price 600Kva Silent Generator, Powered by Cummins KTA19-G8 Engine
- Shanghai
- T/T Credit Card
You May Like
-
Automatic Type 200Kva Cummins Genset, Powered by Cummins 6CTA8.3-G2 Engine
-
100% New in Stock 150Kva Cummins Genset, Powered by Cummins 6BTAA5.9-G2 Engine
-
75Kva Cummins Genset, Powered by Cummins 6BT5.9-G2 Engine
-
Factory Price 600Kva Cummins Genset, Powered by Cummins KTA19-G8 Engine
-
Factory Price 600Kva Cummins Generator Set, Powered by Cummins KTA19-G8 Engine
-
Automatic Type 200Kva Diesel Generator, Powered by Cummins 6CTA8.3-G2 Engine
Product Details
| Place of Origin | Jiangsu, China | Brand Name | 600Kva silent generator | |
| Model Number | KTA19-G8 | Output Type | AC Three Phase | |
| Speed | 1500rpm/min | Frequency | 50Hz | |
| Rated Power | 600Kva | Rated Voltage | 110V~600V | |
| Rated Current | 864A |
Product Description
Specifications
600Kva silent generator, powered by Cummins KTA19-G8 engineStamford alterantor
Deepsea control panel
High quality
600Kva silent generator (KTA19-G8)
Cummins engine
Every generator set is subjected to a comprehensivetest program which includes 50% load, 75% load,100% load, 110% load and the checking and proving of all control and safety shut-down functions;
24V DC start motor;
Equipped with battery charger and 24V highperformance maintenance-free lead-acid startingbatteries and connecting with cables;
Equipped with industrial silencer and flexible exhaust hose;
Equipped with CHINT MCCB circuit breaker;
Designed to Comply with ISO8528/GB2820;
Powered by Cummins engine,Controlled by Deepsea panel
Voltage | HZ | Phase | P.F (COS) | Output (KVA) |
400/230V | 50 | 3 | 0.8 | 600 |
Remark | 60Hz, 220, 380V, 460V, 480V, 600V can be produced as requirements. | |||
Cummins 600Kva diesel generator engine data
Engine Model | KTA19-G8 |
Number of Cylinders | 6 cylinders, Vertical in line |
Cycle | 4 stroke |
Aspiration | Turbocharged and after water cooled |
Bore×Stroke | 159mm x159mm |
Displacement | 18.9L |
Compression ratio | 13.9:1 |
Standby Power/Speed | 575KW / 1500rpm |
Speed Governor | electrical |
Cooling System | Forced water cooling cycle |
Steady speed droop | ≤1% |
Total lubrication system capacity | 50L |
Coolant capacity (engine only) | 30L |
Fuel Consumption at 100% Load | 128L |
Starter Motor | DC24V, |
Alternator | AC24V |
Alternator brand | Stamford, Marathon, Leroy Somer, Mecc-alte, TWGII… |
Prime power | 600Kva |
Frequency/speed | 50HZ/1500rpm (60Hz/1800rpm) |
Exciter type | Single bearing, Brushless, Self-excited |
Power factor | 0.8 |
Voltage adjust range | ≥5% |
Voltage regulation NL-FL | ≤±1% |
Insulation Grade | H |
Protection Grade | IP23 |
The control module gives digital readouts of:
Generator voltage;
Output frequency;
Engine speed;
Battery voltage;
Engine hours run.
The control module has indicators for failure
information:
Overspeed/underspeed,
Emergency stop
Low oil pressure;
High water temperature
Failure to start
Battery charger failure
Automatic shutdown occurs under:
Low engine oil pressure;
High engine water temperature;
Overspeed/underspeed;
Failure to start after three attempts.
600Kva Cummins diesel generator
600Kva Cummins diesel generator (Packing)
