3ph 562.5kva Big Power Diesel Generator Set
- Shanghai
- T/T Credit Card
You May Like
-
500kva Small Silent Diesel Generator Price List
-
High Quality 500kw Diesel Generator Price With Fast Delivery
-
Hot Sale 550kva Electric Generator With High Quality Control Panel
-
Hot Sale 600kva Diesel Generator Container With the Competitve Price
-
High Quality Electric 400kva Silent Diesel Dynamo With Low Price
-
With ATS 750kva Emergency Generator Powered by Cummins KTA38-G2 Engine
Product Details
| Place of Origin | Jiangsu, China | Brand Name | 3ph 562.5kva big power diesel generator set | |
| Model Number | 3ph 562.5kva big power diesel generator set | Output Type | AC Three Phase | |
| Speed | 1800rpm/min | Frequency | 60Hz | |
| Rated Power | 562.5Kva | Rated Voltage | 480V | |
| Rated Current | 676A |
Product Description
3ph 562.5kva big power diesel generator set
Every generator set is subjected to a comprehensivetest program which includes 50% load, 75% load,100% load, 110% load and the checking and proving of all control and safety shut-down functions;
24V DC start motor;
Equipped with battery charger and 24V highperformance maintenance-free lead-acid startingbatteries and connecting with cables;
Equipped with industrial silencer and flexible exhaust hose;
Equipped with CHINT MCCB circuit breaker;
Designed to Comply with ISO8528/GB2820;
Powered by Cummins engine, Controlled by Deepsea panel
Voltage | HZ | Phase | P.F (COS) | Output (KVA) |
480V | 60 | 3 | 0.8 | 562.5 |
Remark | 60Hz, 220, 380V, 460V, 480V, 600V can be produced as requirements. | |||
450Kw diesel generator power capacity
Engine Model | KTA19-G3A |
Number of Cylinders | 6 cylinders, Vertical in line |
Cycle | 4 stroke |
Aspiration | Turbocharged and after water cooled |
Bore×Stroke | 159mm x159mm |
Displacement | 19L |
Compression ratio | 13.9:1 |
Standby Power/Speed | 563KW / 1800rpm |
Speed Governor | electrical |
Cooling System | Forced water cooling cycle |
Steady speed droop | ≤1% |
Total lubrication system capacity | 50L |
Coolant capacity (engine only) | 30L |
Fuel Consumption at 100% Load | 111L |
Starter Motor | DC24V, |
Alternator | AC24V |
Alternator brand | Stamford, Marathon, Leroy Somer, Mecc-alte, TWGII… |
Prime power | 500Kva |
Frequency/speed | 50HZ/1500rpm (60Hz/1800rpm) |
Exciter type | Single bearing, Brushless, Self-excited |
Power factor | 0.8 |
Voltage adjust range | ≥5% |
Voltage regulation NL-FL | ≤±1% |
Insulation Grade | H |
Protection Grade | IP23 |
The control module gives digital readouts of:
Generator voltage;
Output frequency;
Engine speed;
Battery voltage;
Engine hours run.
The control module has indicators for failure
information:
Overspeed/underspeed,
Emergency stop
Low oil pressure;
High water temperature
Failure to start
Battery charger failure
Automatic shutdown occurs under:
Low engine oil pressure;
High engine water temperature;
Overspeed/underspeed;
Failure to start after three attempts.
450Kw diesel generator
450Kw silent diesel generator
