Fast Delivery 750 Kva Soundproof Generator Powered by Cummins KTA38-G2 Engine
- Shanghai
- T/T Credit Card
You May Like
-
Continuous Power 625Kva Cummins Diesel Generator Set, Powered by Cummins KTAA19-G6A Engine
-
Continuous Power 625Kva Cummins Silent Generator Set, Powered by Cummins KTAA19-G6A Engine
-
Continuous Power 625Kva Cummins Silent Diesel Generator, Powered by Cummins KTAA19-G6A Engine
-
Continuous Power 625Kva Cummins Silent Genset, Powered by Cummins KTAA19-G6A Engine
-
Continuous Power 625Kva Cummins Genset, Powered by Cummins KTAA19-G6A Engine
-
Continuous Power 625Kva Cummins Silent Generator, Powered by Cummins KTAA19-G6A Engine
Product Details
| Place of Origin | Jiangsu, China | Brand Name | 750 kva generator | |
| Model Number | KTA38-G2 | Output Type | AC Three Phase | |
| Speed | 1500rpm/min | Frequency | 50Hz | |
| Rated Power | 750 Kva | Rated Voltage | 380/220v | |
| Rated Current | 1080A |
Product Description
750 Kva soundproof generator (Engine model: KTA38-G2)
Cummins engine-KTA38-G2
Every generator set is subjected to a comprehensivetest program which includes 50% load, 75% load,100% load, 110% load and the checking and proving of all control and safety shut-down functions;
24V DC start motor;
Equipped with battery charger and 24V highperformance maintenance-free lead-acid startingbatteries and connecting with cables;
Equipped with industrial silencer and flexible exhaust hose;
Equipped with CHINT MCCB circuit breaker;
Designed to Comply with ISO8528/GB2820;
Powered by Cummins engine,Controlled by Deepsea panel
Voltage | HZ | Phase | P.F (COS) | Output (KVA) |
400/230V | 50 | 3 | 0.8 | 750 |
Remark | 60Hz, 220, 380V, 460V, 480V, 600V can be produced as requirements. | |||
Cummins 750kva generator engine data
Engine Model | KTA38-G2 |
Engine manufacturer | Cummins |
Number of Cylinders | 12 cylinders, V type |
Cycle | 4 stroke |
Aspiration | Turbocharged and after water cooled |
Bore×Stroke | 159mm * 159mm |
Displacement | 37.8L |
Compression ratio | 14.5:1 |
Prime Power/Speed | 664KW / 1500rpm |
Standby Power/Speed | 731KW / 1500rpm |
Speed Governor | Electrical |
Cooling System | Forced water cooling cycle |
Steady speed droop | ≤1% |
Total lubrication system capacity | 135L |
Coolant capacity (engine only) | 118L |
Fuel Consumption at 100% Load | 205g/kw.h |
Starter Motor | DC24V, |
Alternator | DC24 |
Alternator brand | Stamford, Marathon, Leroy Somer, Mecc-alte, TWGII… |
Prime power | 750Kva |
Frequency/speed | 50HZ/1500rpm (60Hz/1800rpm) |
Exciter type | Single bearing, Brushless, Self-excited |
Power factor | 0.8 |
Voltage adjust range | ≥5% |
Voltage regulation NL-FL | ≤±1% |
Insulation Grade | H |
Protection Grade | IP23 |
The control module gives digital readouts of:
Generator voltage;
Output frequency;
Engine speed;
Battery voltage;
Engine hours run.
The control module has indicators for failure
information:
Overspeed/underspeed,
Emergency stop
Low oil pressure;
High water temperature
Failure to start
Battery charger failure
Automatic shutdown occurs under:
Low engine oil pressure;
High engine water temperature;
Overspeed/underspeed;
Failure to start after three attempts.
750Kva Cummins open diesel generator
750Kva Cummins silent diesel generator
750Kva Cummins silent diesel generator (Packing)
750Kva Cummins silent diesel generator (Shipping)
