350KVA 2206C-E13TAG2 silent generator with original Perkin engine
(High quality, Original engine, Low fuel consumption)
Powered by Perkins engine
Every generator set is subjected to a comprehensivetest program which includes 50% load, 75% load,100% load, 110% load and the checking and proving of all control and safety shut-down functions;
24V DC start motor;
Equipped with battery charger and 24V highperformance maintenance-free lead-acid startingbatteries and connecting with cables;
Equipped with industrial silencer and flexible exhaust hose;
Equipped with CHINT MCCB circuit breaker;
Designed to Comply with ISO8528/GB2820;
Powered by UKP engine,Controlled by Deepsea panel
Voltage |
HZ |
Phase |
P.F (COS) |
Output (KVA) |
380/220V |
50 |
3 |
0.8 |
350 |
Remark |
60Hz, 220, 380V, 460V, 480V, 600V can be produced as requirements. |
|||
350kva silent 2206C-E13TAG2 generator with original Perkins engine
Engine Model |
2206C-E13TAG2 |
Number of Cylinders |
6 cylinders, vertical in line |
Cycle |
4 stroke |
Aspiration |
Turbocharged and after water cooled |
Bore×Stroke |
130mm x157mm |
Displacement |
12.5L |
Compression ratio |
16/3:1 |
Prime Power/Speed |
305KW / 1500rpm |
Standby Power/Speed |
349KW / 1500rpm |
Speed Governor |
Electrical |
Cooling System |
Forced water cooling cycle |
Steady speed droop |
≤1% |
Total lubrication system capacity |
40L |
Coolant capacity |
51.4L |
Fuel Consumption at 100% Load |
209g/kw.h |
Starter Motor |
DC24V, |
Alternator |
DC24V |
Alternator brand |
Stamford, Marathon, Leroy Somer, Mecc-alte, TWGII… |
Prime power |
375KVA |
Frequency/speed |
50HZ/1500rpm (60Hz/1800rpm) |
Exciter type |
Single bearing, Brushless, Self-excited |
Power factor |
0.8 |
Voltage adjust range |
≥5% |
Voltage regulation NL-FL |
≤±1% |
Insulation Grade |
H |
Protection Grade |
IP23 |
Phase / wire |
3 phase 4 wires |
The control module gives digital readouts of:
Generator voltage;
Output frequency;
Engine speed;
Battery voltage;
Engine hours run.
The control module has indicators for failure
information:
Overspeed/underspeed,
Emergency stop
Low oil pressure;
High water temperature
Failure to start
Battery charger failure
Automatic shutdown occurs under:
Low engine oil pressure;
High engine water temperature;
Overspeed/underspeed;
Failure to start after three attempts.
Soundproof for optional
